Запчасти Case IH RMX370 (00.100.01[02]) - INITIAL STOCKING LIST (LIST B) 42/47 (00) - GENERAL & PICTORIAL INDEX

1

87630573

TILLAGE BLADE

Gang Assy RR-LF

9шт.

1 thru 9 Applies to 330 Turbo Only

1шт.

2

87574699

TILLAGE BLADE

Gang Assy RR-LF

1шт.

3

87574695

TILLAGE BLADE

Gang Assy RR

1шт.

4

87574698

TILLAGE BLADE

Gang Assy LR

1шт.

5

87630572

TILLAGE BLADE

Gang Assy RF-LR

1шт.

6

87574703

TILLAGE BLADE,466mm OD x 6.5mm Thk

Gang Assy RF-LR

1шт.

7

101190C1

SPOOL

Gang Assy RR-LR-RF-LF

1шт.

8

1263636C1

SPOOL

Gang Assy RR-LR-RF-LF

1шт.

9

1263631C1

SPOOL

Gang Assy RR-LR-RF-LF

1шт.

10

87790840

SEAL

Rockshaft Assy, 75-8 Hub and Spindle Assy

1шт.

11

87476379

BEARING CONE,41.27mm ID x 19.81mm W

Rockshaft Assy, 75-8 Hub and Spindle Assy

1шт.

12

86577076

BEARING ASSY,55.75mm ID x 122.26mm OD x 33.54mm W

Rockshaft Assy, 75-8 Hub and Spindle Assy

1шт.

13

87476393

BEARING CUP,73.43mm OD x 14.73mm W

Rockshaft Assy, 75-8 Hub and Spindle Assy

1шт.

Applies to 330 Turbo Only

1шт.

14

105497H

BEARING CUP,96.85mm OD x 15.77mm W

Rockshaft Assy, 75-8 Hub and Spindle Assy

1шт.

Applies to 330 Turbo Only

1шт.

15

86512015

TAPERED BEARING,41.27mm ID x 73.46mm OD x 19.63mm W

6 - Bolt Tandem Inner/Outer Wings LH & RH, Hub and Spindle

1шт.

16

36726

BEARING CONE,31.75mm ID x 16.76mm W

6 - Bolt Tandem Inner/Outer Wings LH & RH, Hub and Spindle

1шт.

17

594703R1

SLEEVE

6 - Bolt Tandem Inner/Outer Wings LH & RH, Hub and Spindle

1шт.

18

594702R91

SEAL

6 - Bolt Tandem Inner/Outer Wings LH & RH, Hub and Spindle

1шт.

19

84182644

HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 304.8mm Stroke

Hydraulic Transport

1шт.

20

84182654

HYDRAULIC CYLINDER,Double Acting, 34.92mm Rod, 304.8mm Stroke

Hydraulic Transport

1шт.

21

84182645

HYDRAULIC CYLINDER,Double Acting, 34.92mm Rod, 304.8mm Stroke

Hydraulic Transport

1шт.

22

84182647

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 304.8mm Stroke

Hydraulic Transport

1шт.

23

87493928

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 914.4mm Stroke

Hydraulic Wing Fold

1шт.

24

84130855

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 914.4mm Stroke

Hydraulic Wing Fold

1шт.

25

84130961

HYDRAULIC CYLINDER

Hydraulic, Fore-Aft. Leveling

1шт.

26

87519394

LIGHT,12V, 21W, Amber

Package

2шт.

27

87520382

LIGHT

Package

1шт.

28

87519398

LIGHT

Package

1шт.

29

179080

BEARING ASSY,19.06mm ID x 45.25mm OD x 15.49mm W

Center Coulter Hub & Spindle

1шт.

Applies to 330 Turbo Only

1шт.

30

36727

OIL SEAL,38.1mm ID x 59.28mm OD x 13.11mm Thk

Center Coulter Hub & Spindle

1шт.

Applies to 330 Turbo Only

1шт.

31

87388864

HYDRAULIC CYLINDER,Double Acting, 44.45mm Rod, 69.85mm Stroke

Hydrualic Self Leveling

1шт.

32

ST491A

BALL BEARING,45mm ID

Rear Basket Bearing

1шт.

Applies to 330 Turbo Only

1шт.

33

86983463

SPOOL

Gang Assy Center, RF, LF, RR, Inner, and Outer

1шт.

33 thru 38 Applies to RMX 370 42" and RMX 370 47" Only

1шт.

34

86983464

SPOOL

Gang Assy Center, RF, LF, RR, Inner, and Outer

1шт.

35

437773A1

SPOOL

Gang Assy Center and right, RF, LF, RR, Inner, and Outer

1шт.

36

437775A1

SPOOL

Gang Assy Center and right, front, Inner and Outer

1шт.

37

437774A1

SPOOL

Gang Assy Center and right, front, Inner and Outer

1шт.

38

6403260

SHANK

1шт.

39

87493925

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 914.4mm Stroke

Hydraulic Wind Fold

1шт.

Applies to RMX 370 47' Only

1шт.

40

87401019

PLOW DISC

24". x 6.5mm and 5mm SLD,9". SPCNG

1шт.

40 thru 49 Applies to RMX 370 42" and RMX 370 47" Only

1шт.

41

87442998

PLOW DISC

24". x 6.5mm and 5mm SLD,9". SPCNG

1шт.

42

87443000

PLOW DISC

24". x 6.5mm SLD,9". SPCNG

1шт.

43

87443002

PLOW DISC

24". x 6.5mm SLD,9". SPCNG

1шт.

44

87443004

PLOW DISC

24". x 6.5mm SLD,9". SPCNG

1шт.

45

87443006

PLOW DISC

24". x 6.5mm SLD,9". SPCNG

1шт.

46

87442999

PLOW DISC

24". x 5mm SLD,9". SPCNG

1шт.

47

87443001

PLOW DISC

24". x 5mm SLD,9". SPCNG

1шт.

48

87443003

PLOW DISC

24". x 5mm SLD,9". SPCNG

1шт.

49

87443005

PLOW DISC

24". x 5mm SLD,9". SPCNG

1шт.
