Запчасти Case IH RMX370 (00.100.01[02]) - INITIAL STOCKING LIST (LIST B) (00) - GENERAL & PICTORIAL INDEX

1

87492403

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 203.2mm Stroke

1шт.

2

87492404

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 203.2mm Stroke

1шт.

3

87388864

HYDRAULIC CYLINDER,Double Acting, 44.45mm Rod, 69.85mm Stroke

1шт.

4

87388876

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 1066.8mm Stroke

1шт.

5

663557R91

BEARING ASSY,1.625" ID x 2.892" OD x 0.77"

1шт.

6

169329C91

OIL SEAL,63.3mm ID x 95.81mm OD x 8mm Thk

1шт.

7

21871501

BEARING CONE,38.1mm ID x 25.65mm W

1шт.

8

115950

OIL SEAL

1шт.

9

625742C1

ROLLER BEARING,2.1654" ID x 3.5433" OD x 0.9055" W

1шт.

10

193907A1

HOUSING, BEARING,109.971 mm ID x 133 mm OD x 64 mm

1шт.

11

409556A1

BEARING, BALL,55.56mm ID x 110mm OD x 55.56mm W

1шт.

12

195109A1

TRUNNION

Pivot

1шт.

13

87567027

SCRAPER BLADE

Blade, Scraper, Rigid/Cushion Assembly, Rear, RH

1шт.

14

87567021

SCRAPER BLADE

Blade, Scraper, Rigid/Cushion Assembly, Rear, LH

1шт.

15

87567013

SCRAPER

Blade, Scraper, Rigid/Cushion Assembly, Front, RH

1шт.

16

87566995

SCRAPER

Blade, Scraper, Rigid/Cushion, Assembly, Front, LH

1шт.

17

87443003

PLOW DISC

Disc, Plow, Solid, 24" Diameter x 5 mm Thick, 760 R.O.C.

1шт.

18

87443004

PLOW DISC

Disc, Plow, Solid, 24" Diameter x 6.5 mm Thick, 760 R.O.C.

1шт.

19

87443005

PLOW DISC

Disc, Plow, Solid, 24" Diameter x 5 mm Thick, 920 R.O.C.

1шт.

20

87443006

PLOW DISC

Disc, Plow, Solid, 24" Diameter x 6.5 mm Thick, 920 R.O.C.

1шт.

21

87442998

PLOW DISC

Disc, Plow, Feathering Blade, Solid 20" Diameter x 5 mm Thick, 760 R.O.C.

1шт.

22

87442999

PLOW DISC

Disc, Plow, Feathering Blade, Solid 22" x 5 mm Thick, 760 R.O.C.

1шт.

23

87443001

PLOW DISC

Disc, Plow, Feathering Blade, Solid 22" Diameter x 6.5 mm Thick, 760 R.O.C.

1шт.

24

87443000

PLOW DISC

Disc, Plow, Feathering Blade, Solid 22" Diameter x 6.5 mm Thick, 920 R.O.C.

1шт.

25

87443002

PLOW DISC

Disc, Plow, Feathering Blade, Solid 20" Diameter x 5 mm Thick, 760 R.O.C.

1шт.

26

87401019

PLOW DISC

Tine, Coil

1шт.

27

33404416

TINE

Tooth, Spike

10шт.

28

87417736

TOOTH

COBO Dual Amber Light

5шт.

29

87519394

LIGHT,12V, 21W, Amber

COBO Single Red Light W/Black Cover RH

2шт.

30

87520382

LIGHT

COBO Single Red Light W/Black Cover LH

2шт.

31

87519398

LIGHT

Bearing, Long, 9", Heavy

2шт.

32

86983464

SPOOL

Bearing, Long, 9", Heavy

1шт.

33

86983463

SPOOL

Bearing, Long, 9", Heavy

1шт.

34

437773A1

SPOOL

Spacing, Heavy, 9"

1шт.
