Запчасти Case IH K23A (10) - HYDRAULIC CIRCUIT

1

T53218

Manifold

1шт.

2

T52726

RESTRICTOR

2шт.

3

218-5018

FITTING

Nipple - Adapter

1шт.

4

T53221

Accumulator

1шт.

5

T53214

CYLINDER

- Hydraulic 3 x 16

4шт.

6

218-927

ELBOW,90 Degree, 1/2" NPTF Male x 1/2" NPSM Fem Sw

- 90deg. Swivel 1/2 NPT

4шт.

7

218-953

TEE

- Male Branch 1/2 NPT

4шт.

8

T53217

Hose - 3/8 x 96"

4шт.

9

T52731

Hose - 3/8 x 70"

1шт.

10

T53215

Hose - 3/8 x 33"

1шт.

11

T53216

SUPPORT

Hose - 3/8 x 52"

2шт.

12

T53219

Support - Hose

6шт.

13

T53220

Clamp - Hose

6шт.

14

111-538

CARRIAGE BOLT,Short NK, 1/2"-13 x 4", G2

BOLT, CARRIAGE, Short NK, 1/2"-13 x 4", G2

7шт.

15

131-165

NUT,1/2"-13, GA

Nut - Lock 1/2 NC, PL

7шт.

16

111-330

CARRIAGE BOLT,Short NK, 3/8"-16 x 1 3/4", G2

Bolt - Carriage 3/8 x 1-3/4 NC, PL

6шт.

17

131-178

LOCK NUT,Prev Torque, Hex, 3/8" - 16, Gr A

Nut - Bolt 3/8 NC, PL

6шт.

T52653

Tape - Teflon (Not Shown)

1шт.
