Запчасти Case IH 870 (75.200.16) - DOUBLE EDGE REEL ASSEMBLY (75) - SOIL PREPARATION

1

87710115

FRAME

Basket Arm

1шт.

2

87712239

SPACER,19.84mm ID x 31.6mm OD x 57mm L

2шт.

3

87433288

GUIDE BUSHING,31.9mm ID x 38.28mm OD x 31.75mm L

2шт.

4

87381

WASHER,0.81" ID x 1.47" OD x 0.13" Thk

2шт.

5

83980547

BOLT,Hex, 3/4" -10 x 9-1/2", Gr 5

1шт.

6

87710117

ARM

Basket

1шт.

7

24162506

SPRING

1шт.

8

51200158

BUSHING,22.72mm ID x 29.08mm OD x 38.1mm L

1шт.

9

16901495

SPECIAL BOLT

7/8" X 23-1/2" NC, GD5 ZND

1шт.

10

438-31220

PIN,3/16" x 1 1/4", Coiled

1шт.

11

87710116

BRACKET, PIVOT

PIVOT BRACKET

1шт.

12

17414012

WASHER,23.83mm ID x 44.45mm OD x 6.45mm Thk

2шт.

13

17620030

WASHER,32.15mm ID x 47.63mm OD x 10mm Thk

1шт.

14

20090120

SPRING BOX

1шт.

15

20090120

SPRING BOX

1шт.

16

9849647

NUT,7/8"-9, G5

1шт.

17

425-1414

JAM NUT,Jam, 7/8"-9, G5

1шт.

18

87414

LUBE NIPPLE,1/4" - 28

1шт.

19

280375

NUT,3/4"-10, GC

Not Shown

1шт.

Used On 2009 Model Year Only

1шт.

20

280120

BOLT,Hex, 3/4" - 10 x 6", Gr 5

Not Shown

1шт.

Used On 2009 Model Year Only

1шт.

20

14810460

SPECIAL PIN

1шт.

Used On 2010 Model Year And After

1шт.

21

270184

LINCH PIN,6.35mm OD

1шт.

Used On 2010 Model Year And After

1шт.
