Запчасти Case IH 870 (39.100.16[02]) - REAR DISK LEVELER - 11 AND 13 SHANK 2011 (39) - FRAMES AND BALLASTING

1

84411046

FRAME

1шт.

2

280375

NUT,3/4"-10, GC

1шт.

3

09102904

SPACER

4шт.

4

87367

WASHER,1.06" ID x 2" OD x 0.13" Thk

2шт.

5

9626600

NUT,1"-8, GC

2шт.

6

25890100

KIT

1шт.

7

86624170

WASHER,1.03" ID x 1.5" OD x 0.12" Thk

2шт.

8

87730279

HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 101.6mm Stroke

3 x 4

1шт.

9

88871

NUT,1/2"-13, GC

2шт.

10

84216263

PIN,25.4mm OD x 270mm L

1.000" X 10.630"

2шт.

11

86520614

BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 8

2шт.

12

9706701

BOLT,Hex, 3/4" - 10 x 2 1/2", Gr 5

1шт.
