Запчасти Case IH 870 (39.100.14[02]) - REAR DISK LEVELER 2011 11 & 13 SHANK (39) - FRAMES AND BALLASTING

1

84411582

FRAME

Left Hand, 13 Shank

1шт.

1

84411596

FRAME

Right Hand, 13 Shank

1шт.

1

84412087

FRAME

Left Hand, 11 Shank

1шт.

1

84412089

FRAME

Right Hand, 11 Shank

1шт.

2

84412139

FRAME

Center, 11 & 13 Shank

1шт.

3

14816241

CLEVIS PIN

2шт.

4

14700600

COTTER PIN

2шт.

5

25330101

HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 254mm Stroke

1шт.

5

25330101R

REMAN-HYD CYLINDER

870 ECOLO-TIGER DISK RIPPER

1шт.

5

25330101C

CORE-HYD CYLINDER

Return Number

1шт.

6

280286

NUT,1"-8, GB

1шт.

7

87500592

BUSHING,25.5mm ID x 31.84mm OD x 19.05mm L

2шт.

8

09661455

SHIM

1шт.

9

17616021

BUSHING,25.8mm ID x 38.1mm OD x 2.08mm L

1шт.

10

84411530

PIN

1шт.

11

88062

BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 8

1шт.

12

85700693

NUT,5/8" - 11, Gr C

1шт.
