Запчасти Case IH 870 (39.100.05) - MAIN LIFT CYLINDER ATTACHMENT (39) - FRAMES AND BALLASTING

1

87757851

FRAME

7 Shank Main

1шт.

1

84406828

FRAME

7 Shank Main, Start Year: 01-MAR-11

1шт.

1

87758268

FRAME

9 Shank Main

1шт.

1

84406858

FRAME

9 Shank Main, Start Year: 01-MAR-11

1шт.

1

87476751

FRAME

11 Shank Main

1шт.

1

84406786

FRAME

11, 13 Shank Main, Start Year: 01-MAR-11

1шт.

1

87476751

FRAME

13 Shank Main

1шт.

2

87738164

ROCKSHAFT

11 Shank

1шт.

2

87738164

ROCKSHAFT

13 Shank

1шт.

2

87709040

ROCKSHAFT

7 Shank

1шт.

2

87718847

ROCKSHAFT

9 Shank

1шт.

3

87471399

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 406.4mm Stroke

3-1/2 x 16, Ind. Hardened, 7 Shank

1шт.

3

87471400

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 406.4mm Stroke

4 x 16, Ind Hardened, 9 Shank

1шт.

3

87471400R

REMAN-HYD CYLINDER

870, ECOLO-TIGER DISK RIPPER, 4 x 16, Ind Hardened, 9 Shank

1шт.

3

87471400C

CORE-HYD CYLINDER

Return Number

1шт.

3

87471401

HYDRAULIC CYLINDER,Double Acting, 44.45mm Rod, 406.4mm Stroke

4-1/2 x 16, Ind Hardened, 11 And 13 Shank

1шт.

3

87471401R

REMAN-HYD CYLINDER

870 ECOLO TIGER DISK RIPPER, MAIN LIFT CYLINDER ATTACHMENT, 4-1/2 x 16, Ind Hardened, 11 And 13 Shank

1шт.

3

87471401C

CORE-HYD CYLINDER

Return Number

1шт.

4

427-20350

CLEVIS PIN,31.75mm OD x 88.9mm L

7 And 9 Shank

2шт.

4

427-20375

CLEVIS PIN,31.75mm OD x 95.25mm L

11 And 13 Shank

2шт.

5

88182

COTTER PIN,1/4" OD x 2" L

2шт.

6

BN321131

BUSHING,31.75mm ID x 38.73mm OD x 25.4mm L

1шт.

7

87613302

WASHER,1.31" ID x 1.98" OD x 0.18" Thk

2шт.

8

413-14168

BOLT,Hex, 7/8" - 9 x 10-1/2", Gr 5

8шт.

9

87715831

BEARING CAP

Casting

4шт.

10

87703164

BUSHING,143mm ID x 155.7mm OD x 76.2mm L

4шт.

11

87754733

BEARING HOUSING

Casting

4шт.

12

87681198

NUT,Hex, 7/8"-9, 0.45 high

7/8

8шт.
