Запчасти Case IH 870 (88.110.06) - SINGLE POINT HYDRAULIC DEPTH CONTROL - FOR 11 & 13 SHANK (88) - ACCESSORIES

1

84704949

KIT

SINGLE POINT HYDRAULIC DEPTH CONTROL - For 11 & 13 Shank Incl 2-29

1шт.

2

84175397

TUBE,2996 mm L

1шт.

3

84175405

HANDLE

1шт.

4

438-11624

ROLL PIN,6.35mm OD x 38.1mm L

1шт.

5

87708499

BAR

2шт.

6

280119

BOLT,Hex, 5/8" - 11 x 3 1/2", Gr 5

2шт.

7

87365

WASHER,0.66" ID x 1.31" OD x 0.1" Thk

2шт.

8

87630

BOLT,Hex, 5/8" - 11 x 2 1/2", Gr 5

3шт.

9

87338

BOLT,Hex, 5/8" - 11 x 3", Gr 5

1шт.

10

88902

NUT,3/8"-16

5шт.

11

87708500

TUBE,16.66 mm ID x 25.4 mm OD x 42 mm L

2шт.

12

87936

BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5

5шт.

13

84175398

SUPPORT

2шт.

14

87708494

SLIDER

1шт.

15

396153A1

PIN

1шт.

16

87309726

RING

1шт.

17

87613198

WASHER,0.78" ID x 1.25" OD x 0.12" Thk

1шт.

18

396152A1

COMPRESSION SPRING

1шт.

19

280622

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 2 1/2", Gr 5

2шт.

20

280736

NUT,5/16"-18, GC

2шт.

21

396150A1

VALVE, CONTROL

1шт.

22

85700693

NUT,5/8" - 11, Gr C

7шт.

23

87708490

PLATE

1шт.

24

87754729

BAR

2шт.

25

90685C1

HYDRAULIC HOSE,12.70 mm ID x 4825.00 mm, SAE 100R1

1шт.

26

1015396

HYDRAULIC HOSE,12.7mm ID x 3810mm L, SAE 100R17

1шт.

27

216797

45 ELBOW,45 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring

1шт.

28

81827427

HYD CONNECTOR,3/4" - 16 JIC x 3/4" - 16 ORB

1шт.

29

214389

PLUG,3/4" - 16 ORB

1шт.
