Запчасти Case IH 900 SERIES (75.200.05) - RIGID INNER COULTER ASSEMBLY (75) - SOIL PREPARATION

1

49109001

Rigid Inner

1шт.

2

49109000

Rigid Inner

1шт.

3

49526000

Inner, Includes Ref. 4, 5, & Hardware

1шт.

4

49564000

Top

1шт.

5

20092021

CASTING

2шт.

6

49571000

17-1/2" Lg. (Std.)

1шт.

6

49572000

19-1/2" Lg. (Opt.)

1шт.

7

49348000

COULTER

Pivot Stop

1шт.

8

49573000

MOUNTING PARTS

Inner Coulter, Includes 9 & 10

1шт.

9

28163300

HUB ASSY.

Q-633 4-Bolt

1шт.

10

49575000

MOUNTING PARTS

Inner Coulter I/Hub

1шт.

11

49529000

PIPE

Coulter Bottom Collar

1шт.

12

443638A1

PLOW DISC

24" Coulter Blade (Std.)

1шт.

12

33502040

20" (Opt.)

1шт.

12

33502041

20" (Opt.)

1шт.
