Артикул
Название
Примечание
Количество
360997R92
CYLINDER ASSY, hydraulic, 3-1/2 x 8
1шт.
1
352369R2
PIN
lock
2шт.
103373
COTTER PIN,3/32" x 3/4"
Pin, Split (Cotter), 3/32" x 3/4"
2шт.
3
352231R11
PIN
ASSY, cylinder pivot
2шт.
4
354837R1
WASHER
lock pin
2шт.
5
361004R1
BOLT,Hex, 1/2" - 20 x 13 7/16"
cylinder tie
4шт.
25-118
NUT,1/2"-20, G5
1/2-20 hex
4шт.
6
361002R3
HEAD
cylinder
1шт.
7
354836R1
O-RING,0.139" Thk x 3.234" ID, -236, Cl 5, 75 Duro
3-1/4 x 3-1/2 x 1/8
2шт.
8
354051R1
BARREL,3.5035" ID, .429" OD, 10.26" Length
TUBE, cylinder
1шт.
9
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
1шт.
10
354835R1
WASHER
cylinder return tube, use only w/two piece return tube
2шт.
11
354834R2
TUBE
cyl return
1шт.
12
375936R1
BACK-UP RING
WASHER, piston head back-up
2шт.
13
378827R1
O-RING,0.21" Thk x 3.1" ID, -338, Cl 6, 90 Duro
3-1/8 x 3-1/2 x 3/16
1шт.
14
385020R1
NUT
3/4-16 piston rod lock
1шт.
15
361003R1
HEAD
piston
1шт.
16
367615R11
HEAD
W/PLUGS, cylinder
1шт.
444788
DRAIN PLUG,Sq Soc, 1/2"-14 NPTF
PLUG, cylinder head
4шт.
17
361006R1
VALVE ASSY, limit stop
1шт.
18
350429R1
O-RING,0.103" Thk x 0.612" ID, -114, Cl 5, 75 Duro
5/8 x 13/16 x 3/32
1шт.
19
360599R1
O-RING,0.07" Thk x 0.18" ID, -8, Cl 5, 75 Duro
3/16 x 5/16 x 1/16
1шт.
20
361007R11
RETAINER
ASSY, limit stop valve
1шт.
21
361009R1
PLATE
limit stop valve retainer
1шт.
179792
BOLT,Hex, 1/4" - 20 x 9/16"
SCREW, 1/4-20 x 9/16 hex-hd cap
2шт.
22
354047R1
O-RING,0.21" Thk x 1.15" ID, Cl 6
O-RING, 1-1/8 x 1-9/16 x 7/32
1шт.
23
354048R1
WASHER,1.06" ID x 1.5" OD x 0.25" Thk
SEAL, piston rod dust
1шт.
24
354049R1
RETAINER
piston rod dust seal
1шт.
25
360372R1
COLLAR
stroke limit plain half
1шт.
26
360010R1
COLLAR, stroke limit flanged half
1шт.
27
361085R91
CLAMP
stroke limit collar
1шт.
28
361005R12
NO LONGER SERVICED
ROD ASSY, piston
1шт.
29
377952R1
O-RING,0.103" Thk x 0.549" ID, -113, Cl 6, 90 Duro
9/16 x 3/4 x 3/32
2шт.
30
375426R91
COLLAR
ASSY, stroke limit
1шт.
392503R1
PIN
SCREW, thumb
1шт.
363138R92
SEAL KIT
PACKAGE cylinder o-ring, consists of ref nos. 7, 12, 13, 18, 19, 22, 23 & 29
1шт.
Выбрано товаров: 37
