Запчасти Case IH 3300-SERIES (42) - HYDRAULIC RESET CYLINDER

T38333

CYLINDER

- hydraulic, complete (YR. - 69-)

1шт.

1

T38198

TUBE - cylinder (YR. - 69-) 15.36" L

1шт.

221-166

NIPPLE - pipe, 3" Nipple, 3/8" NPT x 3"

1шт.

2

70742

WASHER

2.50", Int, #250, cylinder tube (YR- 69-)

1шт.

3

T38234

WIPER SEAL

- wiper (YR. - 69-)

1шт.

4

T38233

BACK-UP RING,0.891" ID x 1.127" OD x 0.05"

- back-up (YR. - 69-)

1шт.

5

A27352

O-RING,0.859" ID x 1.137" OD x 0.139"

"O" RING - piston rod (YR. - 69-)

1шт.

6

T38193

GLAND - cylinder (YR. - 69-)

1шт.

7

T38236

BACK-UP RING

RING - back-up (YR. - 69-)

1шт.

8

T38237

O-RING,0.103" Thk x 2.3" ID, -141, Cl 5, 75 Duro

"O" RING - gland seal (YR. - 69-)

1шт.

9

A30971

O-RING,0.21" Thk x 2.1" ID, -330, Cl 5, 75 Duro

"O" RING - piston gland (YR. - 69-)

1шт.

10

A35810

RING

- back-up (YR. - 69-)

1шт.

11

T38330

GLAND - pisotn (YR. - 69-)

1шт.

12

A17526

O-RING,0.614" ID x 0.754" OD x 0.7"

"O" RING - piston rod (YR. - 69-)

1шт.

13

T38329

ROD - piston (YR. - 69-)

1шт.

25-1412

JAM NUT,Jam, 3/4"-10, G5

- 3/4" N.C. hex, jam

1шт.
