Запчасти Case IH 80 (09-08[A]) - TRANSPORT UNIT

1

602477R2

LINK, connecting

2шт.

5/8 X 1-3/4" CD-PLTD MACH BOLT W/NUT

4шт.

21/32 X 1-1/4 X 16 GA CD-PLTD WASH.

4шт.

5/8" CD-PLTD LK-WASH.

4шт.

2

602506R1

BUSHING, connecting link

4шт.

3

F14367

EAR, transport draw

2шт.

1/2 X 1-3/8" MACH BOLT W/NUT

2шт.

1/2" LK-WASH.

2шт.

4

608624R1

ANGLE, transport LH

1шт.

4

608625R1

ANGLE, transport RH

1шт.

5/8 X 2-3/16" STD-HD DLD PIN

2шт.

3/16 X 1-1/8" C-PIN

2шт.

5

602472R1

BRACE, transport frame

2шт.

1/2 X 1-1/8" MACH BOLT W/NUT

4шт.

1/2" LK-WASH.

4шт.

6

605570R1

ANGLE, rear transport (10-1/2 ft)

1шт.

6

602493R1

ANGLE, rear transport (12 ft & 14 ft)

1шт.

1/2 X 1-1/8" MACH BOLT W/NUT

2шт.

1/2" LK-WASH.

2шт.
