Запчасти Case IH 55 (07-08) - WHEEL AXLE (TRAIL BEHIND MODELS)

1

663906R1

CAP

wheel hub

2шт.

2

70120D

SLOTTED NUT,7/8"-14

NUT, 7/8" - NF slt axle spindle

2шт.

103387

COTTER PIN,1/8" x 1 1/2"

Pin, Split (Cotter), 1/8" x 1 1/2"

2шт.

3

23071R1

WASHER

29/32 x 2 x 7 ga

2шт.

4

651818R91

ROLLER BEARING,31.77 mm ID x 16.08 mm

CONE, wheel hub outer brg

2шт.

5

651817R1

BEARING CUP

CUP, wheel hub outer brg

2шт.

6

606468R11

HUB

wheel spindle (Includes 1 - 663558R1, cup & 1 - 651817R1, cup)

1шт.

351079R1

BOLT,Hex Counter Shank, 1/2" - 20 x 23/32"

1/2 - NF X 7/8" WHEEL BOLT

12шт.

7

608322R1

EYE, lift link

1шт.

8

608324R1

BAR

ROD, adjustable lift (7 ft, 10 ft & 13 ft models)

1шт.

219792

COLLAR

1-1/4" - NF JAM NUT

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

2шт.

608700R1

WASHER

1-9/32 X 2 X 16 GA WASHER

2шт.

8

609127R1

ROD

adjustable lift (10 ft & 13 ft high clearance model)

1шт.

425-1520

JAM NUT,Jam, 1 1/4"-12, G5

1-1/4" - NF JAM NUT

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

2шт.

608700R1

WASHER

1-9/32 X 2 X 16 GA WASHER

2шт.

9

608325R1

ROD, rigid lift (7 ft, 10 ft & 13 ft models)

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

1шт.

608700R1

WASHER

1-9/32 X 2 X 16 GA WASHER

1шт.

9

609128R1

ROD

rigid lift (10 ft x 13 ft high clearance model)

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

2шт.

608700R1

WASHER

19/32 X 2 X 16 GA WASHER

2шт.

10

608323R1

BUSHING

lift link eye

2шт.

20644R1

WASHER

1.656 X 2.250 X .054 WASHER

2шт.

432-1640

COTTER PIN,1/4" x 2 1/2"

Pin, Split (Cotter), 1/4" x 2 1/2"

2шт.

11

608315R1

SUPPORT

wheel axle long

2шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

2шт.

271727

CAM,Hex, 5/8" - 11 x 3", Gr 5

5/8 X 3" BOLT

8шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8" NUT

8шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

8шт.

12

609134R91

HANGER

axle adapter LH (10 ft & 13 ft high clearance model)

1шт.

271723

SNAP RING,Hex, 5/8" - 11 x 2", Gr 5

5/8 X 2" BOLT

4шт.

413-1052

BOLT,Hex, 5/8" - 11 x 3-1/4", Gr 5

5/8 x 3-1/4" bolt

6шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8" NUT

10шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

10шт.

12

609135R91

HANGER

axle adapter RH (10 ft & 13 ft high clearance model)

1шт.

413-1032

BOLT,Hex, 5/8" - 11 x 2", Gr 5

5/8 X 2" BOLT

4шт.

413-1052

BOLT,Hex, 5/8" - 11 x 3-1/4", Gr 5

5/8 X 3-1/4" BOLT

6шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8" nut

10шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

10шт.

13

608316R91

AXLE

wheel (Includes 1 - 608321R1, spindle)

2шт.

22811R1

WASHER

2-1/32 X 2-3/4 X 14 GA WASHER

4шт.

108660

PIN,5/16" x 3"

Split (Cotter), 5/16" x 3"

4шт.

14

608314R1

SUPPORT

wheel axle short

2шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

2шт.

NLS

NO LONGER SERVICED

5/8 X 1-3/4" BOLT

8шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8" NUT

8шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

8шт.

15

608321R1

SPINDLE

wheel axle (Welded)

2шт.

16

606556R91

OIL SEAL

SEAL, wheel hub (Opt w/ 594704R91, seal)

2шт.

16

594704R91

OIL SEAL

SEAL, wheel hub (Opt w/ 606556R91 seal)

2шт.

17

663557R91

BEARING ASSY,1.625" ID x 2.892" OD x 0.77"

CONE, wheel hub inner brg

2шт.

18

663558R1

BEARING CUP

CUP, wheel hub inner brg

2шт.
