Запчасти Case IH 55 (08-04) - AXLE

1

663906R1

CAP

wheel hub

4шт.

2

70120D

SLOTTED NUT,7/8"-14

NUT, 7/8"-NF slt-hex

4шт.

3

619373R1

WASHER

29/32 x 2 x 7 ga

4шт.

4

651818R91

ROLLER BEARING,31.77 mm ID x 16.08 mm

CONE, axle outer brg

4шт.

5

651817R1

BEARING CUP

CUP, axle outer brg

4шт.

6

606468R1

HUB

wheel

4шт.

7

608322R1

EYE, lift link

2шт.

8

608324R1

BAR

ROD, lifting adjustable (Note A)

2шт.

8

609127R1

ROD

lifting adjustable (Note B)

2шт.

1-1/4"-NF JAM NUT

2шт.

1-9/32 X 2 X 16 GA WASH.

2шт.

1/4 X 2" C-PIN

2шт.

9

608325R1

ROD, lifting rigid (Note A)

2шт.

9

609128R1

ROD

lifting rigid (Note B)

2шт.

1-9/32 X 2 X 16 GA WASH.

2шт.

1/4 X 2" C-PIN

2шт.

10

608323R1

BUSHING

lift rod

4шт.

1-21/32 X 2-1/4 X 16 GA WASH.

4шт.

1/4 X 2-1/2" C-PIN

4шт.

11

608315R1

SUPPORT

long axle

4шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

4шт.

5/8 X 1-5/8" TYPE 2 BOLT W/NUT (Note B)

16шт.

5/8 X 3" BOLT W/NUT (Note A)

16шт.

5/8" LK-WASH.

16шт.

12

609134R91

HANGER

axle LH (Note B)

1шт.

12

609135R91

HANGER

axle RH (Note B)

1шт.

5/8 X 1-7/8" HEX-HD BOLT W/NUT

16шт.

5/8 X 3-1/4" HEX-HD BOLT W/NUT

24шт.

5/8" LK-WASH.

40шт.

13

608316R91

AXLE

(Includes spindle, 608321R1)

4шт.

2-1/32 X 2-3/4 X 14 GA WASH.

8шт.

5/16 X 3" C-PIN

8шт.

14

608314R1

SUPPORT

short axle

4шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

1шт.

5/8 X 1-3/4" TYPE 2 BOLT W/NUT

8шт.

5/8" LK-WASH.

8шт.

15

608321R1

SPINDLE

axle (Welded into axle)

4шт.

16

606556R91

OIL SEAL

SEAL, spindle (Includes sleeve)

4шт.

17

663557R91

BEARING ASSY,1.625" ID x 2.892" OD x 0.77"

CONE, axle inner brg

4шт.

18

663558R1

BEARING CUP

CUP, axle inner brg

4шт.
