Запчасти Case IH 55 (07-10[A]) - ROCKSHAFT AND LIFT PARTS

1

608310R1

BUSHING,32.38mm ID x 50.8mm OD x 25.4mm L

rockshaft outer arm

2шт.

2

608302R91

ROCKSHAFT

7 ft model (Includes 2 - 608310R1, bushing)

1шт.

2

608303R91

ROCKSHAFT

10 ft & 10 ft high clearance model (Includes 2 - 608310R1, bushing)

1шт.

2

608304R91

ROCKSHAFT

13 ft & 13 ft high clearance model (Includes 2 - 608310R1, bushing)

1шт.

3

608311R1

CAP

rockshaft bracket

4шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

4шт.

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

5/8 X 2-1/4" BOLT

8шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

8шт.

4

608312R1

BRACKET

rockshaft

4шт.

413-1032

BOLT,Hex, 5/8" - 11 x 2", Gr 5

5/8 X 2" BOLT

4шт.

271729

BOLT,Hex, 5/8" - 11 x 3 1/2", Gr 5

5/8 X 3-1/2" BOLT

2шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8" NUT

6шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

6шт.

5

5528S

SPACER

rockshaft bracket

2шт.

271729

BOLT,Hex, 5/8" - 11 x 3 1/2", Gr 5

5/8 X 3-1/2" BOLT

2шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8" NUT

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.
