Запчасти Case IH 210 (D-10) - SAFETY CHAIN GUARD

1

665044R1

LOCK, side

2шт.

2

665049R1

SPACER, side rail (58-61)

6шт.

BOLT W/NUT, 3/8 x 1-1/4" hex-hd. mach.

8шт.

WASHER, 3/8 lock

8шт.

575807R1

WASHER

13/32 x 1" x 11 ga.

8шт.

3

665048R1

CHAIN GUARD, side rail

2шт.

4

665045R2

LOCK, front side

2шт.

PIN, 1/8 x 2" cotter

2шт.

5

665050R2

CHAIN GUARD, front side angle

2шт.

6

665051R1

CHAIN GUARD, front hanger LH

1шт.

BOLT W/NUT, 1/2 x 1-1/2" crg.

1шт.

BOLT W/NUT, 3/8 x 1" hex-hd. mach.

2шт.

BOLT W/NUT, 1/2 x 1-1/4" hex-hd. mach.

3шт.

WASHER, 3/8" lock

2шт.

WASHER, 1/2" lock

4шт.

7

665046R2

LOCK, front chain

2шт.

PIN, 1/8 x 2" cotter

2шт.

8

665052R1

CHAIN GUARD, front hanger RH

1шт.

BOLT W/NUT, 1/2 x 1-1/2" crg.

1шт.

BOLT W/NUT, 3/8 x 1" hex-hd. mach.

2шт.

BOLT W/NUT, 1/2 x 1-1/4" hex-hd. mach.

3шт.

WASHER, 3/8" lock

2шт.

WASHER, 1/2" lock

4шт.

9

665053R92

CHAIN, 5/16" coil (6 links)

40шт.

10

665054R92

CHAIN, 5/16" coil (3 links)

83шт.

11

665043R2

LOCK, rear side and rear

3шт.

12

665047R1

CHAIN GUARD, rear side rail (58-61)

3шт.

BOLT W/NUT, 3/8 x 1-1/4" hex-hd. mach.

9шт.

WASHER, 3/8" lock

9шт.

12

463927R1

RAIL, rear (61- )

3шт.

BOLT W/NUT, 3/8" x 1" crg

9шт.

WASHER, 3/8"

9шт.

13

465162R1

BRACKET, chain guard reinforcing LH (61- )

1шт.

13

465163R1

BRACKET, chain guard reinforcing RH (61- )

1шт.

BOLT W/NUT, 3/8 x 1" mach

2шт.

SCREW, 3/8 x 1-1/4" cap

2шт.

WASHER, 3/8" lock

4шт.

WASHER, 13/32 x 7/8" x 7 ga

2шт.
