Запчасти Case IH 110 (01-02) - MAIN FRAME

1

604593R11

BRACKET ASSEMBLY, front furrow wheel

1шт.

3/4 X 2-1/4" CAD-PLTD. HEX-HD. BOLT W/NUT

5шт.

3/4" CAD-PLTD. LOCK WASHER

5шт.

2

605983R91

FRAME ASSEMBLY, 9 ft. (1961-)

1шт.

2

FRAME ASSEMBLY, 9 ft. (1960-61) (Order 1 - 605983R91 frame, 1 - 605980R1 pin and 1 - 605981R1 stop)

1шт.

2

605985R91

FRAME ASSEMBLY, 13-1/2 & 18 ft. (1961-)

1шт.

2

FRAME ASSEMBLY, 13-1/2 & 18 ft. (1960-61) (Order 1 - 605985R91 frame, 1 - 605980R1 pin and 1 - 605981R1 stop)

1шт.

3

604649R91

BRACKET ASSEMBLY, pivot frame

1шт.

3/4 X 2-1/4" HEX-HD. BOLT W/NUT

6шт.

3/4" LOCK WASHER

6шт.

4

604577R1

SPACER

tie bar

2шт.

5

604605R1

BAR, tie

1шт.

3/4 X 2-1/2" CAD-PLTD. HEX-HD BOLT W/NUT

2шт.

25/32 X 1-3/4 X 11 GA. WASHER

2шт.

3/4" CAD-PLTD. LOCK WASHER

2шт.

6

604578R1

"U" BOLT, hitch carrier (18 ft.)

1шт.

7

604594R1

CARRIER, hitch (18 ft.)

1шт.

8

604651R91

EXTENSION ASSEMBLY, main frame (18 ft.)

1шт.

3/4 X 2-1/4" CAD-PLTD. HEX-HED. BOLT W/NUT

6шт.

3/4" CAD-PLTD. LOCK WASHER

6шт.

9

602968R1

BUSHING

thrust rod

1шт.
