Запчасти Case IH 690 (75.200.13) - WING DISK GANG (7 SHANK REAR WING ASSY) (QUANTITIES FOR ONE GANG ASSY) 2006 MODELS & PRIOR

Схема запчастей Case IH 690 - (75.200.13) - WING DISK GANG (7 SHANK REAR WING ASSY) (QUANTITIES FOR ONE GANG ASSY) 2006 MODELS & PRIOR
27
34
21
17
4
11
35
25
43
38
29
3
31
40
8
26
39
1
37
5
11
35
23
32
12
13
12
2
33
23
14
38
47
41
42
49
20
19
16
30
24
36
10
9
24
32
46
13
8
18
28
44
37
45
6
7
15
48
22

Артикул

Название

Примечание

Количество

1

395103A1

TUBE

Wing Gang Tube Weldment, Lh 7-shank

1шт.

395104A1

TUBE

Wing Gang Tube Weldment, Rh 7-shank

1шт.

2

398264A1

ANGLE

Scraper, Lh

1шт.

398263A1

ANGLE

Scraper, Rh

1шт.

3

195939A1

BRACKET

Assembly - Disk, Lh

5шт.

4

195938A1

SCRAPER

Assembly - Disk, Rh

5шт.

5

398765A1

PLOW BOLT

Arbor, 1-1/2 Round

1шт.

6

425-1224

SLOTTED NUT,1 1/2"-6, G5

Hex

1шт.

7

87412142

WASHER,40mm ID x 75mm OD x 6.5mm Thk

Arbor, 1-1/2 Dia.

1шт.

8

139773C1

WASHER

Washer - End

2шт.

9

118888A1

HUB

Spool - Spacing, 12

2шт.

10

409778A1

SPOOL

Bearing, Long 12

2шт.

11

409776A1

SPOOL

Bearing, Short, 12

2шт.

NSS

NOT SOLD SEPARAT

Cushion - Bearing & Standard, Trunnion (409577A1)

2шт.

12

195109A1

TRUNNION

Pivot

4шт.

13

197334A1

BUSHING,32.13mm ID x 63.83mm OD x 25.91mm L

Special Bonded

4шт.

NSS

NOT SOLD SEPARAT

Bearing Assembly - Trrunnion (409555A1)

2шт.

14

409556A1

BEARING, BALL,55.56mm ID x 110mm OD x 55.56mm W

Trunnion

2шт.

15

101-21433

SNAP RING,#433, 4.641", Int

2шт.

16

193929A1

WASHER,79 mm ID x 109 mm OD x 3.35 mm

Bearing Retainer

2шт.

17

193907A1

HOUSING, BEARING,109.971 mm ID x 133 mm OD x 64 mm

Housing - Bearing, Trunnion (193907A1)

2шт.

18

219-87

LUBE NIPPLE,1/4" - 28 NPTF

2шт.

19

193831A1

SPRING

Bearing Standard

2шт.

20

413-1244

BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5

4шт.

21

492-11075

LOCK WASHER,3/4"

4шт.

22

495-21081

WASHER,3/4"

4шт.

23

409805A1

BUSHING

Arbor Bolt Support

2шт.

24

118886A1

BUSHING,38.91mm ID x 44.45mm OD x 295mm L

Arbor Bolt Support

2шт.

25

87442997

PLOW DISC

Blade - 24 Dia. X 6.5 mm thk

3шт.

26

87442995

PLOW DISC

DISK, 22"X6.5MM CC PLAIN

1шт.

27

87442985

PLOW DISC

Blade - 20 Dia. X 6.5 mm thk

1шт.

28

410081A1

BAR

Gang Holder, Top

1шт.

29

409775A1

WEAR PLATE

Mount - Scraper Angle

1шт.

30

410082A1

STRAP

Gang Holder

2шт.

31

413-12120

BOLT,Hex, 3/4" - 10 x 7-1/2", Gr 5

4шт.

32

280375

NUT,3/4"-10, GC

4шт.

33

17413011

WASHER

1.75 X .812, ZP

2шт.

34

413-14112

BOLT,Hex, 7/8" - 9 x 7", Gr 5

2шт.

35

87681198

NUT,Hex, 7/8"-9, 0.45 high

7/8, NC Stover

2шт.

36

17414012

WASHER,23.83mm ID x 44.45mm OD x 6.45mm Thk

1.75 X .938, ZP

1шт.

37

433-1032

CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2", Gr 5

2шт.

38

1256884C1

NUT

5/8, NC, Flange Lock

2шт.

39

231425A1

BOLT

1/2, NC Special

5шт.

40

86512371

SERRATED NUT,Flg, USR, 1/2"-13

5шт.

NSS

NOT SOLD SEPARAT

Cushion - Bearing & Standard, Rh, Flange (406684A1)

2шт.

NSS

NOT SOLD SEPARAT

Cushion - Bearing & Standard, Lh, Flange (409177A1)

2шт.

41

405202A1

PLATE

Bearing Support

2шт.

42

ST740B

BALL BEARING,55.58mm ID

Bearing - Flange

2шт.

42

ST740BGV

BEARING

Value, Ball Bearing

2шт.

43

193831A1

SPRING

Bearing Standard

2шт.

44

413-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5

8шт.

45

86992215

LOCK NUT,1/2"-13, GC

Stover

8шт.

46

413-1248

BOLT,Hex, 3/4" - 10 x 3", Gr 5

4шт.

47

280375

NUT,3/4"-10, GC

4шт.

48

495-21081

WASHER,3/4"

4шт.

49

438-12036

LOCK PIN,5/16" x 2 1/4", Slotted

1шт.

Выбрано товаров: 56
