Запчасти Case IH 485 (8-14) - KIT HYDRAULIC CYLINDER SEAL FOR CYLINDERS 60200C - 61107C - 61110C (08) - HYDRAULICS

1

548392R92

SEAL KIT

Incl 2 - 12

1шт.

2

403460R1

WIPER SEAL,38mm ID x 50.9mm OD x 7.94mm Thk

1шт.

3

383770R1

WASHER

1шт.

4

404015R1

BACK-UP RING

1шт.

5

383771R1

SEALING WASHER

1шт.

6

140600C1

RETAINING WIRE

1шт.

7

231-46114

LOCK NUT,7/8"-14, GB

1шт.

8

375936R1

BACK-UP RING

2шт.

9

403622R1

BACK-UP RING

1шт.

10

70924840

O-RING,-236, 90 Duro, 3.234" ID x .139" Thk

1шт.

11

238-6338

O-RING,0.21" Thk x 3.1" ID, -338, Cl 6, 90 Duro

1шт.

12

238-6325

O-RING,0.21" Thk x 1.475" ID, -325, Cl 6, 90 Duro

1шт.
