Запчасти Case IH 37 (D-13) - REMOTE CONTROL CYLINDER PARTS, SPECIAL, HYDRAULIC EQUIPMENT, FOR TRACTORS WITH PIPE THREAD COUPLING

1

651977R1

BRACKET, cylinder stop, 1955 to 1956, 2 used all units

1шт.

BOLT W/NUT, 5/8 x 1-1/2 mach, 4 used all units

1шт.

WASHER, 5/8 lock, 4 used all units

1шт.

2

651978R1

ARM, cylinder stop, Serial Range: 1955-1956

1шт.

BOLT W/NUT, 5/8 x 2-5/8 mach

1шт.

WASHER, 5/8 lock

1шт.

3

650991R1

BUSHING, cylinder stop, Serial Range: 1955-1956

1шт.

517843R1

COTTER PIN

PIN, quick-attachable cotter

1шт.

Q1237

PIN,3/4" x 2 1/2"

3/4 x 2-1/2 dld-std-hd

1шт.

4

651982R91

STOP ASSY, cylinder, Serial Range: 1955-1956

1шт.

BOLT W/NUT, 5/8 x 1-1/2 mach, 4 used all units

1шт.

WASHER, 5/8 lock, 4 used all units

1шт.

5

652822R1

LATCH

cylinder mounting, Serial Range: 1955-1959

1шт.

PIN, 3/16 x 1-1/8 cotter

1шт.

Q5137

AXLE PIN

PIN, 1/2 x 1-3/8 dld-std-hd

1шт.

6

652829R91

STOP ASSY, cylinder, Serial Range: 1956-1959

1шт.

BOLT W/NUT, 5/8 x 1-1/2 mach, 4 used all units

1шт.

517843R1

COTTER PIN

PIN, quick attachable cotter

1шт.

WASHER, 5/8 lock, 4 used all units

1шт.

7

653673R2

LATCH

cylinder mounting, 1959 and since

1шт.

PIN, 3/16 x 1-1/8 cotter

1шт.

Q5137

AXLE PIN

PIN, 1/2 x 1-3/8 dld-std-hd

1шт.

8

653738R91

SUPPORT

STOP ASSY, cylinder, 1959 and since

1шт.

BOLT W/NUT, 5/8 x 1-1/2 mach, 2 used units D, G, J and L 3 used units A, B, C, E, F, H, I, K, M and N

1шт.

PIN, 1/8 x 1 cotter

1шт.

Q875

HEADED PIN,3/8" x 1 5/16"

PIN, 3/8 x 1-5/16 dld-std-hd

1шт.

9

653715R1

FRAME, angle, 1959 and since, 1 used units H thru N

1шт.

9

651981R1

FRAME, angle, 1955 to 1959, 1 used units H thru N

1шт.

BOLT W/NUT, 5/8 x 1-1/2 mach, 2 used units H thru N

2шт.

PIN, 1/8 x 1 cotter, 1 used units H thru N

1шт.

Q875

HEADED PIN,3/8" x 1 5/16"

PIN, 3/8 x 1-5/16 dld-std-hd, 1 used units H thru N

1шт.

WASHER, 5/8 lock, 2 used units H thru N

1шт.

10620P

WASHER

21/32 x 1-1/2 x 16 ga, 2 used units H thru N

1шт.

360997R95

CYLINDER

CYLINER, hydraulic, 3-1/2 x 8 in., refer to cyl, 1 for components

1шт.

353216R91

COUPLING

1шт.

357962R91

HOSE

ASSY, 96 in.

2шт.

15135EDX

CYLINDER, 2-1/4 x 8 in., note B, for all machines except 7 and 8 ft. sizes

2шт.

15246EAX

CYLINDER, 1-3/4 x 8 in., note B, for 7 and 8 ft. machines

2шт.

371292R95

CYLINDER

hydraulic, 3-1/2 x 8 in., refer to cyl, 1 for components

1шт.

395149R1

QUICK MALE COUPLING

COUPLING

2шт.

372437R91

HOSE

ASSY, 112 in.

2шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

4шт.
