Запчасти Case IH 350 (9-28) - FRONT AND REAR GANGS AND GANG BARS (09) - CHASSIS/ATTACHMENTS

13

468584R2

SQ HOLE WASHER

- bumper, front gangs

2шт.

14

466950R2

WASHER

- arbor bolt, rear gangs

2шт.

14

100696C1

WASHER

furrow filler, rear gangs

2шт.

15

468607R1

BOLT,1 1/8"-7 x 39.8"

- arbor, 1-1/8 NC x 39-13/16 inch

1шт.

(Disk Harrow coded B)

2шт.

(Disk Harrow coded C)

4шт.

15

468608R1

BOLT,1 1/8"-7 x 41.3"

- arbor, 1-1/8 NC x 41-5/16 inch

1шт.

(Disk Harrow coded B)

2шт.

(Disk Harrow coded A)

4шт.

15

468582R2

BOLT (SPREADER),1 1/8"-7 x 76.7"

BOLT - arbor, 1-1/8 NC x 76-7/16 inch

1шт.

(Disk Harrow coded Q)

2шт.

(Disk Harrow coded N)

4шт.

15

468583R2

BOLT (SPREADER),1 1/8"-7 x 79.4"

BOLT - arbor, 1-1/8 NC x 79-7/16 inch

1шт.

(Disk Harrow coded Q)

2шт.

15

471013R1

BOLT,1 1/8"-7 x 56.3"

- arbor, 1-1/8 NC x 56-5/16 inch

1шт.

(Disk Harrow coded H)

2шт.

(Disk Harrow coded G)

4шт.

15

471014R1

BOLT,1 1/8"-7 x 48.8"

- arbor, 1-1/8 NC x 48-13/16 inch

1шт.

(Disk Harrow coded D, E and F)

4шт.

15

471015R1

BOLT,1 1/8"-7 x 57.8"

- arbor, 1-1/8 NC x 57-13/16 inch

1шт.

(Disk Harrow coded H)

2шт.

(Disk Harrow coded J)

4шт.

15

472585R2

BOLT,1 1/8"-7 x 64.4"

- arbor, 1-1/8 NC x 64-7/16 inch

1шт.

(Disk Harrow coded K)

4шт.

15

472586R2

BOLT,1 1/8"-7 x 71.9"

- arbor, 1-1/8 NC x 71-15/16 inch

1шт.

(Disk Harrow coded M)

4шт.

15

468583R2

BOLT (SPREADER),1 1/8"-7 x 79.4"

BOLT - arbor, 1-1/8 NC x 79-7/16 inch

1шт.

(Disk Harrow coded P)

4шт.

15

652939R2

BOLT,Rnd Cor Sq Hd, 1 1/8" - 7 x 67.4"

- arbor, 67.4 inch

1шт.

(Disk Harrow coded L)

4шт.

15

481844R1

BOLT,1 1/8"-7 x 85.4"

- arbor, 1-1/8 NC x 85-7/16 inch

1шт.

(Disk Harrow coded T)

2шт.

(Disk Harrow coded R)

4шт.

15

481845R1

BOLT,1 1/8"-7 x 86.9"

- arbor, 1-1/8 NC x 86-15/16 inch

1шт.

(Disk Harrow coded T)

2шт.

(Disk Harrow coded S)

4шт.

492-11112

LOCK WASHER,1 1/8"

WASHER - lock, 1-1/8, 1 per arbor bolt

1шт.

220094

NUT,1 1/8"-7, G5

- hex, 1-1/8 NC, 1 per arbor bolt

1шт.

16

472589R1

SUPPORT - scraper bar (Disk Harrow coded K, L, M, N, P and Q)

1шт.

(Units without third bearing attachment)

4шт.

589068R1

WASHER

- flat, 21/31 x 1-1/4 x 0.138 inch (3.5 mm) thick

4шт.
