Запчасти Case IH 310 (9-056) - HITCH, 12 FOOT OR 16 FOOT SINGLE MACHINE, AND REAR DUPLEXED OR TRIPLEXED MACHINE (09) - CHASSIS/ATTACHMENTS

Схема запчастей Case IH 310 - (9-056) - HITCH, 12 FOOT OR 16 FOOT SINGLE MACHINE, AND REAR DUPLEXED OR TRIPLEXED MACHINE (09) - CHASSIS/ATTACHMENTS
4
5
3
6
7
2
2
1

Артикул

Название

Примечание

Количество

1

813746C1

BEAM

ASSEMBLY - hitch 95.65 inch

1шт.

2

813707C1

PIN

- hitch beam

2шт.

432-1640

COTTER PIN,1/4" x 2 1/2"

Pin, Split (Cotter), 1/4" x 2 1/2"

4шт.

21214R1

WASHER

- flat, 1-5/32 x 2 x 7/64 inch

4шт.

3

813743C1

STABILIZER

ASSEMBLY - 12 foot hitch, 23.05 inch

1шт.

3

813742C1

STABILIZER

ASSEMBLY - 16 foot hitch, 30.06 inch

1шт.

4

597043R1

PIN

ASSEMBLY - hitch stabilizer

1шт.

432-1640

COTTER PIN,1/4" x 2 1/2"

Pin, Split (Cotter), 1/4" x 2 1/2"

1шт.

5

597075R1

BAR - hitch stabilizer, asjusting, 28.8 inch

1шт.

597061R2

PIN

- headed, 5/8 x 2.2 inch

2шт.

599744R1

AXLE PIN

PIN - hair, internal

2шт.

23313R1

HEADED PIN,7/8" x 3 1/2"

PIN, HEADED, 7/8" x 3 1/2"

1шт.

432-1624

COTTER PIN,1/4" x 1 1/2"

Pin, Split (Cotter), 1/4" x 1-1/2"

1шт.

6

811435C2

ARM

ASSEMBLY - hitch steering, 45.5 inch

1шт.

7

597069R2

BAR

- extension, 47.0 inch

1шт.

597061R2

PIN

- headed, 5/8 x 2.2 inch

2шт.

1978738C1

HAIR PIN COTTER

internal

2шт.

Выбрано товаров: 17
