Запчасти Case IH 132 (AE-6) - SCRAPERS AND SCRAPER ANGLES

1

P34101

LOCK

arbor bolt nut

4шт.

2

PA4167

WASHER

nut, for units A through F

4шт.

2

481611R1

WASHER

nut, for units G & H

4шт.

3

481416R1

SPOOL

spacing, 16 for unit A, 8 for unit B, 20 for unit D, 10 for unit E, 24 for unit G

1шт.

3

481417R1

SPOOL

spacing, 6 for unit B, 12 for unit C, 8 for unit E, 16 for unit H

1шт.

4

472592R3

SPOOL

bearing, 4 for units A, D & G, 4 for untis B & E

1шт.

5

479021R1

BAR

brg std

8шт.

413-1060

BOLT,Hex, 5/8" - 11 x 3-3/4", Gr 5

SCREW, 5/8-11 x 3-3/4 znd hex-hd cap

16шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

16шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 C-Z hex.

16шт.

6

485752R1

SUPPORT ASSY.

STANDARD ASSY, brg

8шт.

7

652386R1

FLANGE

bearing mounting

6шт.

18508R1

CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd

BOLT, 3/8-16 x 3/4 znd sq-nk crg

8шт.

441485R1

BOLT,Shoulder, Hex, 3/8" - 16 x 1 1/2"

3/8 step to 1/2 shank znp

24шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

32шт.

120377

NUT,3/8" - 16, Gr 5

32шт.

8

ST607A

BALL BEARING,44.82mm ID x 85mm OD x 41.33mm W

BEARING, std ball

8шт.

9

652383R1

BUSHING,38.91mm ID x 44.45mm OD x 128.6mm L

arbor bolt support, 8 for units A, D & G, 4 for units B & E

1шт.

9

472594R1

BUSHING,38.91mm ID x 44.45mm OD x 154mm L

arbor bolt support, 6.06 in. long, 4 for units B & E, 8 for units C, F & H

1шт.

9

112410C1

TUBE

BUSHING, arbor bolt support, 8.66 in long, used only with spool, 101191C1, 8 for units F and H

1шт.

10

472591R3

BUSHING,1.796" ID x 2.4" OD x 4.052"

bearing, square hole

8шт.

10

101191C1

SPOOL

bearing, round hole

8шт.

11

140561/2

DISC

DISK. 18 in. solid-light 10 ga

1шт.

11

143521/2

NOTCHED DISK

DISK, 18 in. notched-regular 10 ga

1шт.

11

482072R1

DISC

DISK, 20 in. solid-light 10 ga

1шт.

11

143811/2

DISC

DISK, 20 in. solid-regulat 9 ga

1шт.

11

474254R1

BLADE

DISK, 20 in. notched-light 10 ga

1шт.

11

143531/2

NOTCHED DISK

DISK, 20 in. notched-regular 9 ga

1шт.

11

471218R1

DISK, 22 in. solid-regular 7 ga

1шт.

11

474255R1

DISC

DISK, 22 in. notched-light 9 ga

1шт.

11

P24425

DISC

DISK, 22 in. notched-regular 7 ga, 28 for unit A & F, 26 for unit B, 24 for unit C, 32 for units D & H, 30 for unit E, 36 for unit G

1шт.

12

474352R3

SQ HOLE WASHER

bumper

2шт.

13

466950R2

WASHER

arbor, machines built, Serial Range: 1969-1976

2шт.

13

100696C1

WASHER

arbor, machines built 1976 and since

2шт.

14

471014R1

BOLT,1 1/8"-7 x 48.8"

arbor, 48.8 in. long, for units A, B & C

4шт.

14

471013R1

BOLT,1 1/8"-7 x 56.3"

arbor, 56.3 in. long, 4 for unit D, 2 for unit E

1шт.

14

471015R1

BOLT,1 1/8"-7 x 57.8"

arbor, 5738 in. long, 2 for unit E, 4 for unit F

1шт.

14

472585R2

BOLT,1 1/8"-7 x 64.4"

arbor, 64.4 in. long, for unit G

4шт.

14

652939R2

BOLT,Rnd Cor Sq Hd, 1 1/8" - 7 x 67.4"

arbor, 67.4 in. long, for unit H

4шт.

425-1018

NUT,1 1/8"-7, G5

1-1/8 pln type 5

4шт.

15

472593R3

SPOOL

bearing, square hole, 4 for units B and E, 8 for units C, F and H

1шт.

15

101190C1

SPOOL

bearing, round hole, 8 for units F and H built 1976 & since

1шт.

16

ST491A

BALL BEARING,45mm ID

BEARING W/LUBRICATION FITTING, ball, optional w/ref. no. 17

8шт.

16

ST491A-IMPGV

BEARING

Value, 1-3/4 In. Round Bore Bearing Assy

8шт.

17

BEARING ASSY, ball, optional w/ST 491A, consists of (2) flange 652386R1, (1) bearing ST607A

1шт.
