Запчасти Case IH 122 (9-16) - SCRAPERS AND SCRAPER ANGLES (09) - CHASSIS/ATTACHMENTS

4

474418R2

ANGLE

- rear scraper bar, right-hand (Disk Harrow coded E)

1шт.

4

474426R2

ANGLE

- front scraper bar, left-hand (Disk Harrow coded J or M)

1шт.

4

474427R2

ANGLE

- front scraper bar, right-hand (Disk Harrow coded J or M)

1шт.

4

474428R2

ANGLE

- rear scraper bar, left-hand (Disk Harrow coded J)

1шт.

4

474429R2

ANGLE

- rear scraper bar, right-hand (Disk Harrow coded J)

1шт.

4

468560R2

BAR

ANGLE - rear scraper bar (Disk Harrow coded K, L or M)

2шт.

4

471009R3

ANGLE

- front scraper bar, left-hand (Disk Harrow coded K or L)

1шт.

4

471010R3

ANGLE

- front scraper bar, right-hand (Disk Harrow coded K or L)

1шт.

413-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5

1шт.

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, 1/2"

1шт.

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex (Disk Harrow coded A or B) 1/2"-13, G5

8шт.

(Disk Harrow coded C through M)

16шт.
