Запчасти Case IH TM255 (75.908.010) - ACS ROUND, 2 BAR COIL (75) - SOIL PREPARATION

1

47765890

CHANNEL,CHANNEL, TINE, 130.02 IN

Tine

5шт.

2

47559052

TINE

Spring

72шт.

3

47957741

CLAMP

Tine

72шт.

4

87689

BOLT,1/2"-13 x 1.813" OAL, Gr 5

144шт.

5

88871

NUT,1/2"-13, GC

224шт.

6

47765837

CHANNEL,CHANNEL, TINE, 112.69 IN

Tine

2шт.

7

47746942

CHANNEL,CHANNEL, TINE, 95.35 IN

Tine

1шт.

8

47746955

CHANNEL,CHANNEL, TINE, 86.69 IN

Tine

2шт.

9

47746951

CHANNEL,CHANNEL, TINE, 78.02 IN

Tine

1шт.

10

47765866

CHANNEL,CHANNEL, TINE, 138.69 IN

Tine

1шт.

11

47916960

BASKET

Round Tube, 90"

2шт.

12

47451691

BEARING CONE

Peer

20шт.

13

47453057

SPINDLE

Bearing, Hard

20шт.

14

47817917

PLATE

Bearing Hanger

16шт.

15

47598753

TUBE

Basket Mount, 90"

2шт.

16

88556

BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 5

64шт.

17

85700693

NUT,5/8" - 11, Gr C

80шт.

18

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

12шт.

19

87613192

WASHER,0.66" ID x 1.75" OD x 0.24" Thk

20шт.

20

280420

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5, Full Thd

80шт.

21

84296836

BASKET

Round Tube, 67"

4шт.

22

47916958

Round Tube, 60"

TUBE

2шт.

23

47916984

Basket Mount, 127"

TUBE

2шт.

24

86507000

BOLT,Hex, 5/8" - 11 x 6 1/2", Gr 5

4шт.

25

47916959

Round Tube, 75"

2шт.

26

47916985

Basket Mount, 142"

TUBE

2шт.
