Запчасти Case IH TM255 (75.908.010) - ACS ROUND, 2 BAR COIL (75) - SOIL PREPARATION

1

47765837

CHANNEL,CHANNEL, TINE, 112.69 IN

Tine

7шт.

2

47559052

TINE

Spring

67шт.

3

47957741

CLAMP

Tine

67шт.

4

87689

BOLT,1/2"-13 x 1.813" OAL, Gr 5

134шт.

5

88871

NUT,1/2"-13, GC

166шт.

6

47746955

CHANNEL,CHANNEL, TINE, 86.69 IN

Tine

2шт.

7

47746951

CHANNEL,CHANNEL, TINE, 78.02 IN

Tine

1шт.

8

47746942

CHANNEL,CHANNEL, TINE, 95.35 IN

Tine

1шт.

9

47765890

CHANNEL,CHANNEL, TINE, 130.02 IN

Tine

1шт.

10

47916960

BASKET

Round Tube, 90"

2шт.

11

47451691

BEARING CONE

Peer

16шт.

12

47453057

SPINDLE

Bearing, Hard

16шт.

13

47817917

PLATE

Bearing Hanger

14шт.

14

47598753

TUBE

2шт.

15

88556

BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 5

56шт.

16

85700693

NUT,5/8" - 11, Gr C

70шт.

17

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

12шт.

18

87613192

WASHER,0.66" ID x 1.75" OD x 0.24" Thk

16шт.

19

280420

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5, Full Thd

64шт.

20

84296836

BASKET

Round Tube, 67"

2шт.

21

47916958

Round Tube, 60"

TUBE

2шт.

22

47916984

Basket Mount, 127"

TUBE

2шт.

23

86507000

BOLT,Hex, 5/8" - 11 x 6 1/2", Gr 5

2шт.

24

47916975

Basket Mount, 120"

TUBE

2шт.

25

47916962

Round Tube, 120"

TUBE

2шт.
