Запчасти Case IH TM255 (75.908.020) - ACS, 3 BAR SPIKE (75) - SOIL PREPARATION

1

47596263

TUBE

Basket Mount, 135"

1шт.

2

47817917

PLATE

Bearing Hanger

11шт.

3

47453057

SPINDLE

Bearing, hard

12шт.

4

47451691

BEARING CONE

Flanged, Peer

12шт.

5

47432098

BASKET

8 Bar, 75"

1шт.

6

47449563

BASKET

8 Bar, 60"

1шт.

7

88556

BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 5

44шт.

8

85700693

NUT,5/8" - 11, Gr C

55шт.

9

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

10шт.

10

87613192

WASHER,0.66" ID x 1.75" OD x 0.24" Thk

12шт.

11

86507000

BOLT,Hex, 5/8" - 11 x 6 1/2", Gr 5

1шт.

12

280420

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5, Full Thd

48шт.

13

88871

NUT,1/2"-13, GC

66шт.

14

47598753

TUBE

Basket Mount, 90"

4шт.

15

47449567

BASKET

8 Bar, 90"

4шт.

16

47959200

ANGLE

17 Spike

3шт.

17

33407513

SHOVEL

Harrow

51шт.

18

16306050

U-BOLT

51шт.

19

88902

NUT,3/8"-16

172шт.

20

47859141

PLATE

Harrow

4шт.

21

02323001

BUSHING

18шт.

22

80700

WASHER,0.56" ID x 1.38" OD x 0.11" Thk

36шт.

23

9707516

BOLT,1/2"-13 x 1-3/4", Cl 5

108шт.

24

47959195

ANGLE

10 Spike

12шт.

25

47962957

LINK BLOCK

Harrow, RH Pull

3шт.

26

47962958

LINK BLOCK

Harrow, Straight Pull

7шт.

27

88011

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

10шт.

28

17407015

WASHER

70шт.

29

270184

LINCH PIN,6.35mm OD

10шт.

30

80012047

BOLT,Hex, 3/8" - 16 x 4", Grade 5

30шт.

31

47963674

CHAIN

1/4 x 25.5 Long

10шт.

32

47963675

CHAIN

1/4 x 14.28 Long

30шт.

33

47796613

TUBE

23.5" Stub

2шт.
