Запчасти Case IH TM255 (75.908.010) - ACS ROUND, 2 BAR COIL (75) - SOIL PREPARATION

1

47746951

CHANNEL,CHANNEL, TINE, 78.02 IN

Tine

2шт.

2

47559052

TINE

Spring

50шт.

3

47957741

CLAMP

Tine

50шт.

4

87689

BOLT,1/2"-13 x 1.813" OAL, Gr 5

100шт.

5

88871

NUT,1/2"-13, GC

116шт.

6

47746953

CHANNEL,CHANNEL, TINE, 60.68 IN

Tine

6шт.

7

47746955

CHANNEL,CHANNEL, TINE, 86.69 IN

Tine

2шт.

8

47746942

CHANNEL,CHANNEL, TINE, 95.35 IN

Tine

2шт.

9

84296836

BASKET

Round Tube, 67"

2шт.

10

47451691

BEARING CONE

Peer

12шт.

11

47453057

SPINDLE

Bearing, Hard

12шт.

12

47817917

PLATE

Bearing Hanger

12шт.

13

47916980

TUBE

Basket Mount, 67"

2шт.

14

88556

BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 5

48шт.

15

85700693

NUT,5/8" - 11, Gr C

60шт.

16

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

12шт.

17

87613192

WASHER,0.66" ID x 1.75" OD x 0.24" Thk

12шт.

18

280420

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5, Full Thd

80шт.

19

47916960

BASKET

Round Tube, 90"

4шт.

20

47598753

TUBE

4шт.
