Запчасти Case IH TM255 (75.908.020) - ACS, 3 BAR SPIKE (75) - SOIL PREPARATION

1

47596247

TUBE

Basket Mount, 150"

1шт.

2

47817917

PLATE

Bearing Hanger

9шт.

3

47453057

SPINDLE

Bearing, Hard

12шт.

4

47451691

BEARING CONE

Flanged, Peer

12шт.

5

47449567

BASKET

8 Bar, 90"

1шт.

6

47449563

BASKET

8 Bar, 60"

5шт.

7

88556

BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 5

36шт.

8

85700693

NUT,5/8" - 11, Gr C

45шт.

9

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

6шт.

10

87613192

WASHER,0.66" ID x 1.75" OD x 0.24" Thk

12шт.

11

86507000

BOLT,Hex, 5/8" - 11 x 6 1/2", Gr 5

3шт.

12

280420

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5, Full Thd

48шт.

13

88871

NUT,1/2"-13, GC

78шт.

14

47597584

TUBE

Basket Mount, 120"

2шт.

15

47959200

ANGLE

17 Spike

3шт.

16

33407513

SHOVEL

135шт.

17

16306050

U-BOLT

135шт.

18

88902

NUT,3/8"-16

312шт.

19

47859141

PLATE

Harrow

12шт.

20

02323001

BUSHING

30шт.

21

80700

WASHER,0.56" ID x 1.38" OD x 0.11" Thk

32шт.

22

9707516

BOLT,1/2"-13 x 1-3/4", Cl 5

8шт.

23

47959199

ANGLE

14 Spike

6шт.

24

48027363

LINK

Harrow, RH Pull

3шт.

25

48027368

LINK

Harrow, Straight Pull

3шт.

26

80700

WASHER,0.56" ID x 1.38" OD x 0.11" Thk

12шт.

27

9707516

BOLT,1/2"-13 x 1-3/4", Cl 5

6шт.

28

47963674

CHAIN

1/4 x 25.5 Long

6шт.

29

17407015

WASHER

42шт.

30

88011

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

6шт.

31

270184

LINCH PIN,6.35mm OD

6шт.

32

48034301

CHAIN

1/4 x 14.28 Long

18шт.

33

80012047

BOLT,Hex, 3/8" - 16 x 4", Grade 5

18шт.

34

48026529

BUSHING

2шт.

35

9706689

BOLT,Hex, 3/8" - 16 x 1 3/4", Gr 5

1шт.

36

88902

NUT,3/8"-16

1шт.
