Запчасти Case IH TM255 (75.908.010) - ACS ROUND, 2 BAR COIL (75) - SOIL PREPARATION

1

47765866

CHANNEL,CHANNEL, TINE, 138.69 IN

Tine

1шт.

2

47559052

TINE

Spring

50шт.

3

47957741

CLAMP

Tine

50шт.

4

87689

BOLT,1/2"-13 x 1.813" OAL, Gr 5

80шт.

5

88871

NUT,1/2"-13, GC

132шт.

6

47765837

CHANNEL,CHANNEL, TINE, 112.69 IN

Tine

2шт.

7

47765890

CHANNEL,CHANNEL, TINE, 130.02 IN

Tine

3шт.

8

47817917

PLATE

Bearong, Hanger

9шт.

9

47453057

SPINDLE

Bearing, Hard

12шт.

10

47451691

BEARING CONE

Peer

12шт.

11

84296836

BASKET

Round Tube, 67"

3шт.

12

47916959

Round Tube, 75"

TUBE

1шт.

13

47916985

Round Tube, 142"

TUBE

1шт.

14

88556

BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 5

36шт.

15

85700693

NUT,5/8" - 11, Gr C

45шт.

16

86977740

BOLT,Hex, 5/8" - 11 x 4", Gr 5

6шт.

17

87613192

WASHER,0.66" ID x 1.75" OD x 0.24" Thk

12шт.

18

86507000

BOLT,Hex, 5/8" - 11 x 6 1/2", Gr 5

3шт.

19

280420

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5, Full Thd

48шт.

20

47916958

Round Tube, 60"

TUBE

2шт.

21

47916984

Round Tube, 127"

TUBE

2шт.
