1
87423771
CYLINDER ASSY.,Double Acting, 31.75mm Rod, 203.2mm Stroke
3-1/2 x 8, Rephase
2шт.
84255910R
REMAN-HYD CYLINDER
200, TIGERMATE II, Reman For New P/N 87423771
2шт.
84255910C
CORE-HYD CYLINDER
Return Number
1шт.
2
87423770
HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 203.2mm Stroke
3-1/4 x 8, Rephase
2шт.
87423770R
REMAN-HYD CYLINDER
200, TIGERMATE II CASE IH FIELD CULTIVATOR
2шт.
87423770C
CORE-HYD CYLINDER
Return Number
1шт.
3
25340301
CYLINDER ASSY.,Double Acting, 38.1mm Rod, 762mm Stroke
4" x 30", 3000 PSI
2шт.
3
25340362
HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 914.4mm Stroke
4" x 36", 3000 PSI, 34-1/2' to 38-1/2' Models
2шт.
3
25340362R
REMAN-HYD CYLINDER
200 - TIGERMATE & TIGERMATE II CASE IH FIELD CULTIVATOR,
2шт.
3
25340362C
CORE-HYD CYLINDER
Return Number
2шт.
4
407167A1
HOSE ASSY.
1/4 x 175, 10 Mainframe
2шт.
4
1264171C1
HYDRAULIC HOSE,6.40 mm ID x 5590.00 mm, SAE 100R1
1/4 x 215, 12 Mainframe
2шт.
4
227185A1
HYDRAULIC HOSE,6.35 mm ID x 6350.00 mm, SAE 100R1
1/4 x 250, 14 Mainframe
2шт.
4
189348A1
HYDRAULIC HOSE,6.40mm ID x 7110mm L
1шт.
4
193759A1
HYDRAULIC HOSE
1шт.
5
1254530C2
HYDRAULIC HOSE
1/4 x 130
2шт.
6
1337374C1
HYDRAULIC HOSE
1/2 x 270, 10 Mainframe
1шт.
6
113710A1
HOSE
1/2 x 295, 12 Mainframe
1шт.
6
134209A1
HOSE
1/2 x 345, 14 Mainframe
1шт.
6a
91202C1
HYDRAULIC HOSE,12.70 mm ID x 2160.00 mm, SAE 100R1
Assy. 112 x 85, All Mainframes
1шт.
6b
1337360C1
HOSE ASSY.
1/2 x 175, 10 Mainframe
1шт.
6b
91205C1
HYDRAULIC HOSE,12.70 mm ID x 5335.00 mm, SAE 100R1
Assy. 1/2 x 175, 12 Mainframe
1шт.
6b
1978106C1
HOSE
Assy. 1/2 x 240, 14 Mainframe
1шт.
8
25600676
HYDRAULIC HOSE,0.38" ID x 88.00", SAE 100R17
20-1/2' and 22-1/2' Models
1шт.
8
25600669
HYDRAULIC HOSE,9.65mm ID x 2895.6mm L, SAE 100R17
24-1/2', 26-1/2' and 28-1/2' Models
1шт.
8
25600671
HYDRAULIC HOSE,0.38" ID x 138.00", SAE 100R17
30-1/2', 32-1/2', 34-1/2' and 36-1/2' Models
1шт.
8
25600752
HYDRAULIC HOSE,9.68mm ID x 161mm L
38-1/2' Models
1шт.
9
25600692
HYDRAULIC HOSE,0.38" ID x 108.00", SAE 100R17
20-1/2' and 22-1/2' Models
1шт.
9
25600684
HYDRAULIC HOSE,0.38" ID x 132.00", SAE 100R17
30-1/2' and 32-1/2' Models
1шт.
9
25600717
HYDRAULIC HOSE,0.38" ID x 155.00", SAE 100R17
34-1/2' and 36-1/2' Models
1шт.
9
25600752
HYDRAULIC HOSE,9.68mm ID x 161mm L
38-1/2' Models
1шт.
9
25600667
HYDRAULIC HOSE,0.38" ID x 187.00", SAE 100R17
1шт.
10
25600724
HYDRAULIC HOSE,0.38" ID x 104.50", SAE 100R17
20-1/2' and 22-1/2' Models
1шт.
10
25600734
HYDRAULIC HOSE,0.38" ID x 124.50", SAE 100R17
24-1/2', 26-1/2' and 28-1/2' Models
1шт.
10
25600814
HYDRAULIC HOSE
3/8 x 148, 30-1/2', 32-1/2', 34-1/2' and 36-1/2' Models
1шт.
10
25600615
HYDRAULIC HOSE,0.38" ID x 173.00", SAE 100R17
38-1/2' Models
1шт.
11
25600606
HYDRAULIC HOSE,0.38" ID x 150.00", SAE 100R17
20-1/2' and 22-1/2' Models
1шт.
11
25600615
HYDRAULIC HOSE,0.38" ID x 173.00", SAE 100R17
24-1/2', 26-1/2' and 28-1/2' Models
1шт.
11
25600733
HYDRAULIC HOSE,0.38" ID x 197.00", SAE 100R17
30-1/2' Model with 10-1/2' Mainframe
1шт.
11
25600718
HYDRAULIC HOSE,0.38" ID x 215.00", SAE 100R17
30-1/2' and 32-1/2' Models with 12-1/2' Mainframe
1шт.
11
25600759
HYDRAULIC HOSE
34-1/2' and 36-1/2' Models
1шт.
11
25600760
HYDRAULIC HOSE
38-1/2' Models
1шт.
12
25600678
HYDRAULIC HOSE,0.38" ID x 78.00", SAE 100R17
10-1/2 Mainframe
1шт.
12
25600704
HYDRAULIC HOSE,9.53mm ID x 2463.8mm L, SAE 100R17
12-1/2 Mainframe
1шт.
12
25600681
HYDRAULIC HOSE,0.38" ID x 121.00", SAE 100R17
3/8 x 121, 14-1/2 Mainframe
1шт.
13
25600429
HYDRAULIC HOSE,0.25" ID x 26.00", SAE 100R17
10-1/2 Mainframe
1шт.
13
25600422
HYDRAULIC HOSE,0.25" ID x 30.00", SAE 100R17
12-1/2 Mainframe
1шт.
13
25600434
HYDRAULIC HOSE,0.25" ID x 34.00", SAE 100R17
14-1/2 Mainframe
1шт.
14
147878C1
HOSE
1/4 x 65, 10-1/2 Mainframe
1шт.
14
25600436
HYDRAULIC HOSE,0.25" ID x 84.00", SAE 100R17
12-1/2 Mainframe
1шт.
14
1284366C1
HYDRAULIC HOSE
1/4 x 100, 14-1/2 Mainframe
1шт.
15
25600429
HYDRAULIC HOSE,0.25" ID x 26.00", SAE 100R17
10-1/2 Mainframe
1шт.
15
25600438
HYDRAULIC HOSE,0.25" ID x 16.00", SAE 100R17
12-1/2 Mainrfame
1шт.
15
1284278C1
HYDRAULIC HOSE
1/4 x 41, 14-1/2 Mainframe
1шт.
16
25600422
HYDRAULIC HOSE,0.25" ID x 30.00", SAE 100R17
10-1/2 Mainframe
1шт.
16
25600437
HYDRAULIC HOSE,0.25" ID x 48.00", SAE 100R17
12-1/2 Mainframe
1шт.
16
1277717C1
HYDRAULIC HOSE,6.35 mm ID x 1525.00 mm
14-1/2 Mainframe
1шт.
17
25600713
HYDRAULIC HOSE,0.38" ID x 27.50", SAE 100R17
10-1/2 Mainframe
1шт.
17
25600738
HYDRAULIC HOSE,0.38" ID x 33.50", SAE 100R17
12-1/2 Mainframe
1шт.
17
25600614
HYDRAULIC HOSE,0.38" ID x 36.00", SAE 100R17
14-1/2 Mainframe
1шт.
18
14891660
SPECIAL PIN,25.4mm OD x 125.73mm L
1 x 4.30
4шт.
20
218-5106
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
8шт.
21
218-5128
ELBOW,90° Elbow, 9/16" - 18 Male JIC x 3/4" - 16 Male ORB
SAE
4шт.
22
218-653
4 WAY CONNECTION,9/16"-18, 37 Degree
Cross JICM
2шт.
23
218-754
CAP,37 Degree, 9/16"-18
JICM
2шт.
24
218-594
TEE,3/4"-16, 37 Degree
JICM
2шт.
25
218-5058
HYD CONNECTOR,9/16" - 18 Male JIC x 3/4" - 18 Male ORB
2шт.
28
218-5059
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
4шт.
29
22510700
HOSE CLAMP,15.86mm
5/8
1шт.
29
22510710
HOSE CLAMP
3/4
1шт.
30
87404919
STOP
12, Transport
2шт.
32
14891630
SPECIAL PIN,25.4mm OD x 162.05mm L
1 x 5.75
4шт.
33
433-616
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1", Gr 5
NC
1шт.
35
413-640
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
NC
2шт.
36
86992213
NUT
3/8, NC, Stover
1шт.
37
289862C1
CABLE TIE,3/16" x 7"
CABLE STRAP Clamp
1шт.
38
14720411
COTTER PIN
PIN, COTTER 1/8 x 2, Split Hairpin
2шт.
39
14810251
HEADED PIN,15.88mm OD x 96.77mm L
5/8 x 3
2шт.
40
495-21106
WASHER,1"
Standard
2шт.
41
17616011
BUSHING
1, Machine, 10 ga
2шт.
42
432-1632
COTTER PIN,1/4" x 2"
Split
1шт.
43
25705041
COUPLING
ISO, 3/4 SAEF
4шт.
44
87328528
SHUT-OFF VALVE
Hydraulic Shut Off
1шт.
45
87328931
PLATE
Bracket
1шт.
46
87343258
DECAL
Hydraulic Transport Operation
1шт.
47
87353780
DECAL
Warning Crushing Hazard
1шт.
48
87353782
DECAL
Transport Hazard
1шт.
49
413-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5
2шт.
50
86992212
NUT
Stover, 5/16 Hex
2шт.
