Запчасти Case IH TIGERMATE II (44.100.19) - DOUBLE FOLD WALKING BEAM SERVICE KIT (38-1/2 (12 MAINFRAME) THROUGH 60-1/2 MODELS (44) - WHEELS

1

04661850

PIN

Axle

1шт.

2

21932510

SEAL

2.29 Bore, CR22870

2шт.

3

06400573

SPACER

Seal

2шт.

4

21871501

BEARING CONE,38.1mm ID x 25.65mm W

1.50 Bore, Timken #2776

2шт.

5

17498D

TAPERED BEARING," ID x 76.2125 mm OD x 23.9135 mm

3.00 OD, Timken #2720

2шт.

6

14032409

NUT

Hex Jam, 1-1/2, NC

1шт.

7

16806045

SET SCREW,Sq Hd, 3/8" - 16 UNC x 1"

Square Head Set, 3/8 x 1, NC

1шт.

8

425-146

JAM NUT,3/8" - 16, Gr 5

1шт.

9

06400540

BEARING ASSY

Service Kit, Includes Ref. 1 - 8

1шт.
