Артикул
Название
Примечание
Количество
1
T28957
CABLE - wing lift (5/16" x 11' - 6") (YR. 64-)
2шт.
2
MT2366S
CLAMP - cable, 5/16" (YR. 64-)
8шт.
3
MT2367S
THIMBLE - cable, 5/16" (YR. 64-)
2шт.
4
T28946
SUPPORT - truss rod (YR. 64-)
2шт.
113-713
BOLT,Hex, 3/4" - 10 x 1-3/4", Gr 5
4шт.
192-27
LOCK WASHER,3/4"
WASHER, LOCK, 3/4"
4шт.
129-108
NUT,3/4"-10, G5
4шт.
5
T28948
BAR - mounting, cable (YR. 64-)
4шт.
6
T28965
PIN
- sheave (YR. 64-)
2шт.
132-313
COTTER PIN,1/4" x 2"
PIN, Split (Cotter), 1/4" x 2"
2шт.
195-111
WASHER,1"
- 2-1/2" x 1-1/16" x 8 ga.
2шт.
219-1
LUBE NIPPLE,1/8" - 27 NPTF
FITTING - grease, 1/8"
2шт.
7
T28966
SHEAVE - with A55256 bushing (YR. 64-)
2шт.
7a
A55256
BUSHING
- (Not shown) (YR. 66-)
2шт.
8
T29021
FRAME - wing, R.H. (YR. 64-)
1шт.
86505993
BOLT,Hex, 1/2" - 13 x 4", Gr 5
12шт.
113-411
BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5
6шт.
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
18шт.
129-105
NUT,Hex, 1/2" - 13, Gr 5
18шт.
113-902
BOLT,Hex, 1" - 8 x 3-1/2", Gr 5
2шт.
129-110
NUT,1"-8, G5
2шт.
129-150
NUT,Jam, 1"-8, G5
- 1" N.C. hex. jam
2шт.
9
T29022
FRAME - wing, L.H. (Hardware same as ref. no. 8) (YR. 64-)
1шт.
10
T28940
U-BOLT
"U" BOLT - (Repl. by T50871) (YR. 64-)
14шт.
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
28шт.
129-105
NUT,Hex, 1/2" - 13, Gr 5
28шт.
11
T28930
BRACKET - truss rod, R.H. (YR. 64-)
1шт.
12
T28931
BRACKET - truss rod, L.H. (YR. 64-)
1шт.
13
T28926
BRACKET - center, truss rod, R.H. (YR. 64-)
1шт.
14
T28927
BRACKET - center, truss rod, L.H. (YR. 64-)
1шт.
15
T28932
ROD - truss (YR. 64-)
2шт.
131-657
LOCK NUT,3/4"-10, GB
NUT - lock, 3/4"
4шт.
16
T28928
BRACKET - truss rod, R.H. (YR. 64-)
1шт.
17
T28929
BRACKET - truss rod, L.H. (YR 64-)
1шт.
18
T28915
BAR - pivot, R.H. (YR. 64-67)
1шт.
19
T28916
BAR - pivot, L.H. (YR. 64-67)
1шт.
21
T37944
GUIDE - cable (YR. 67-)
4шт.
22
T29045
BRACKET (YR. 64-)
2шт.
113-411
BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5
4шт.
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
4шт.
129-105
NUT,Hex, 1/2" - 13, Gr 5
4шт.
23
T37945
GUIDE - cable (YR. 64-67)
2шт.
24
T28900
FRAME - extension (YR. 64-)
2шт.
113-412
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
16шт.
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
16шт.
129-105
NUT,Hex, 1/2" - 13, Gr 5
16шт.
25
T28896
EXTENSION (YR. 64-)
2шт.
113-411
BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5
8шт.
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
8шт.
129-105
NUT,Hex, 1/2" - 13, Gr 5
8шт.
26
T28897
PLATE - mounting (YR. 64-)
4шт.
27
T35636
EXTENSION - medium short, 9" (YR. 67-)
2шт.
111-513
BOLT
- 1/2" x 4-1/2" N.C. cge.
8шт.
192-23
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
8шт.
129-105
NUT,Hex, 1/2" - 13, Gr 5
8шт.
Выбрано товаров: 56
