Запчасти Case IH 82-SERIES (B-20[A]) - DISC COVERING ATTACHMENT, WITH SEED FIRMING WHEEL ONE PER ROW

1

PO2942

BRACKET

adjusting

2шт.

2

PO11454A

BOLT

EYEBOLT, covering disk bearing

2шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 c-z hex.

2шт.

608081R1

WASHER

21/32 x 1-3/4 x 11 ga c-z

2шт.

3

541704R1

SUPPORT ASSY.

STANDARD, covering disk

2шт.

222502

SCREW

5/16-18 x 3/4 hex. soc-fil-pt set

2шт.

4

526769R91

BALL BEARING,30mm OD x 98.04mm L

BEARING, covering disk

2шт.

5

479473R1

DISC

DISK, 11 inch

2шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

SCREW, 5/16-18 x 3/4 znd hex-hd cap

12шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

12шт.

120376

NUT,5/16"-18, G5

12шт.

6

478035R1

BEARING HOUSING,109 mm OD x 19.3 mm

disk brg inner

2шт.

7

478036R1

BEARING HOUSING,30.023 mm ID x 69 mm OD x 19.3 mm

disk bearing outer

2шт.

480679R1

WASHER

dirt seal felt

2шт.

8

516595R1

COLLAR

set

2шт.

85-15010

SET SCREW,Sq Hd, 1/2"-13 x 5/8"

SCREW, 1/2-13 x 5/8 sq-hd cup-pt set

2шт.

9

484153R91

FRAME ASSY, carrying

1шт.

10

484155R91

ROD ASSY, spring pressure

1шт.

17452R1

BOLT,Hex, 1/2"-13 x 1 1/4", G2

1/2 x 1-1/4 znd hex-hd mach

1шт.

NLS

NO LONGER SERVICED

17/32 x 1-1/16 x 13 ga c-z

1шт.

120384

WASHER,1/2"

LOCK, 1/2"

1шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

1шт.

11

484158R1

WASHER

BUSHING, pressure rod

1шт.

12

PO104

VALVE SPRING

SPRING

1шт.
