Артикул
Название
Примечание
Количество
1
522506R2
TURNBUCKLE
ROD, upper parallel
1шт.
522510R1
BAR
SWIVEL, upper parallel link rear, RH thd
1шт.
19289R1
BOLT, 1/2 x 3/4 in. cd-pltd mach
1шт.
3
522591R1
PLUG
CUSHION, upper parallel link locking bushing fibre
1шт.
4
522520R1
PLATE, tool bar outer attaching, tapped
1шт.
5
522537R1
SPACER
tool bar attaching plate
1шт.
6
522521R1
PLATE, tool bar outer attaching, not tapped
1шт.
523060R1
BOLT, 1/2 x 2-1/4 in. heat-treated crg
1шт.
18810R1
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 2
1/2 x 2-1/4 in. C-Z mach
1шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
7
86636814
LUBE NIPPLE,1/4"-28 x .52" lg
FITTING, straight 1/4 in. lubrication, Lower parallel link pivot bolt
1шт.
8
522544R2
BOLT
lower parallel link rear pivot
1шт.
426897
JAM NUT,Jam, 3/4"-10, G5
3/4 in. C-Z jam
1шт.
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
WASHER, LOCK, 3/4"
1шт.
9
516595R11
COLLAR,16.67mm ID x 28.5mm OD x 19mm L
COLLAR W/SET SCREW, lift rod
1шт.
85-15010
SET SCREW,Sq Hd, 1/2"-13 x 5/8"
SCREW, 1/2 x 5/8 in. cup-pt sq-hd set
1шт.
10
467644R1
ROD, lift
1шт.
11
522523R1
LINK, lower parallel outer
1шт.
12
522532R1
RETAINER
WASHER, lower parallel link bearing
1шт.
13
522543R2
BOLT,Hex, 3/4" - 10 x 2 3/4"
lower parallel link front pivot
1шт.
426897
JAM NUT,Jam, 3/4"-10, G5
3/4 in. C-Z jam
1шт.
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
WASHER, LOCK, 3/4"
1шт.
14
BRACKET, left and right head, discontinued for service
1шт.
80722
LUBE NIPPLE,3/16" x .55" lg, Drive
FITTING, 3/16 hole lub
2шт.
15
522498R1
BOLT,U, 3/4" - 10 x 6 5/16"
U-BOLT, head bracket
1шт.
467750R1
WASHER
25/32 x 1-1/2 in. x 11 ga C-Z
1шт.
16
522508R1
BOLT,U, 1/2" x 3 1/8"
U-BOLT, lift arm
1шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
17
467645R91
ARM ASSY.
ARM ASSEMBLY, long lift
1шт.
NLS
NO LONGER SERVICED
3/8 x 1 in. rd-hd
1шт.
18
522509R1
BAR
SWIVEL, upper parallel link front, LH thd
1шт.
19
CLIP, lift arm, discontinued for service
1шт.
20
525670R2
BAR
LOCK, frame
1шт.
Выбрано товаров: 36
