Артикул
Название
Примечание
Количество
1
66584D
FITTING
3/16 in. drive type straight lubrication
1шт.
2
483587R1
WASHER
pivot
1шт.
3
483583R91
TUBE ASSY, hitch
1шт.
425-1012
NUT,3/4"-10, G5
3/4 in.
4шт.
271612
BOLT,Hex, 3/4" - 10 x 2 1/4", Gr 5
SCREW, 3/4 x 2-1/4 in. hex-hd cap
4шт.
103326
LOCK WASHER,3/4"
WASHER, LOCK, 3/4"
4шт.
4
484490R91
SUPPORT ASSY, see note
1шт.
5
483561R1
BOLT
U-BOLT, wheel arm, see note
1шт.
425-1014
NUT,7/8"-9, G5
NUT, 7/8"-9, G5
2шт.
103327
LOCK WASHER,7/8"
WASHER, LOCK, 7/8"
2шт.
6
483554R1
PLATE, attaching, not tapped, see note
1шт.
7
483553R1
PLATE, attaching, tapped, see note
1шт.
8
462402R1
BOLT
U-BOLT
1шт.
425-1014
NUT,7/8"-9, G5
NUT, 7/8"-9, G5
2шт.
103327
LOCK WASHER,7/8"
WASHER, LOCK, 7/8"
2шт.
9
483574R91
TUBE ASSY, transport
1шт.
10
486220R1
PIN
transport tube pointed
1шт.
11
483579R91
AXLE ASSY, wheel
1шт.
13
472220R21
HUB
W/FITTING, wheel
1шт.
443804
SCREW, 1/4 x 1/4 in. C-Z pltd slt-or-pt hdls set
1шт.
14
507843R1
PIN, quick-attachable cotter
1шт.
16
651815R91
BEARING ASSY,7.508" ID x 17.82" OD x 6"
CONE ASSY, outer bearing
1шт.
16
651815R91GV
BEARING CONE
Value, Cone Bearing
1шт.
17
651814R1
BEARING CUP
CUP, outer bearing
1шт.
18
651194R1
CAP
wheel bearing hub
1шт.
19
463036R1
WHEEL (STEERING)
WHEEL ASSY, 14 x 5J, recommended tire size 8.50 x 14, 8.00 x 14, 7.50 x 14 or 7.00 x 14
1шт.
20
351079R1
BOLT,Hex Counter Shank, 1/2" - 20 x 23/32"
conical head
4шт.
69442D
NUT
slt-hex
1шт.
103386
COTTER PIN,1/8" x 1 1/4"
Pin, Split (Cotter), 1/8" x 1 1/4"
1шт.
575813R1
WASHER
25/32 x 1-1/4 x 11 ga
1шт.
21
483578R1
SECTION, bracket
1шт.
22
484486R91
BRACKET ASSY, hitch left, see note
1шт.
23
484487R91
BRACKET ASSY, hitch right, see note
1шт.
24
651866R1
PIN, pointed
1шт.
25
483588R91
BRACKET ASSY, pivot
1шт.
137323
COTTER PIN,5/16" x 2 1/2"
Pin, Split (Cotter), 5/16" x 2 1/2"
1шт.
472221R91
SEAL,39.57mm ID x 58.6mm OD x 7.37mm Thk
wheel hub oil
2шт.
472222R1
SLEEVE
oil seal wear
2шт.
Выбрано товаров: 40
