Артикул
Название
Примечание
Количество
1
522506R2
TURNBUCKLE
ROD, upper parallel
1шт.
2
522510R1
BAR
SWIVEL, upper parallel link rear, RH thd
1шт.
22882R1
BOLT,Hex, 1/2"-13 x 3/4", G2
1/2 x 3/4 type 1
1шт.
3
522591R1
PLUG
CUSHION, upper parallel link locking bushing fibre
1шт.
4
522520R1
PLATE, tool bar outer attaching, tapped
1шт.
5
522537R1
SPACER
tool bar attaching plate
1шт.
6
522521R1
PLATE, tool bar outer attaching, not tapped
1шт.
523060R1
BOLT, 1/2 x 2-1/4 in. heat-treated crg
1шт.
18810R1
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 2
1/2 x 2-1/4 in. C-Z mach
1шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
7
86636814
LUBE NIPPLE,1/4"-28 x .52" lg
FITTING, straight 1/4 in. lubrication, Lower parallel link pivot bolt
1шт.
8
522544R2
BOLT
lower parallel link rear pivot
1шт.
426897
JAM NUT,Jam, 3/4"-10, G5
3/4 in. C-Z jam
1шт.
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
WASHER, LOCK, 3/4"
1шт.
9
516595R11
COLLAR,16.67mm ID x 28.5mm OD x 19mm L
COLLAR W/SET SCREW, lift rod
1шт.
85-15010
SET SCREW,Sq Hd, 1/2"-13 x 5/8"
SCREW, 1/2 x 5/8 in. cup-pt sq-hd set
1шт.
10
522503R1
ROD, lift
1шт.
523061R1
WASHER
21/32 x 1-3/8 in. x 11 ga case hardened
1шт.
11
522523R1
LINK, lower parallel outer
1шт.
12
522532R1
RETAINER
WASHER, lower parallel link bearing
1шт.
13
522543R2
BOLT,Hex, 3/4" - 10 x 2 3/4"
lower parallel link front pivot
1шт.
426897
JAM NUT,Jam, 3/4"-10, G5
3/4 in. C-Z jam
1шт.
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
WASHER, LOCK, 3/4"
1шт.
14
BRACKET, left head, also rockshaft support, discontinue for service
1шт.
14
BRACKET, left head, also rockshaft support, discontinued for service
1шт.
15
522498R1
BOLT,U, 3/4" - 10 x 6 5/16"
U-BOLT, head bracket
1шт.
467750R1
WASHER
25/32 x 1-1/2 in. x 11 ga C-Z
1шт.
16
522508R2
U-BOLT, lift arm, for 1-1/4 in. sq rockshaft
1шт.
16
523378R1
BOLT,U, 1/2" - 13 x 3 1/4"
U-BOLT, lift arm, for 1-3/8 in. sq rockshaft
1шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
17
ARM, long lift, (56), discontinued for service
58шт.
18
522509R1
BAR
SWIVEL, upper parallel link front, LH thd
1шт.
19
468022R1
TRUNNION
lift arm
1шт.
20
ARM, left long lift, (58), order 525666R91
60шт.
21
ARM, right long lift, (58), order 525666R91
60шт.
NLS
NO LONGER SERVICED
3/8 x 1 in. rd-hd
1шт.
22
525666R91
ARM ASSEMBLY, long lift
1шт.
23
CLIP, lift arm, discontinued for service
1шт.
24
525670R2
BAR
LOCK, frame
1шт.
Выбрано товаров: 42
