Запчасти Case IH 600 (39.100.04) - 9 FIVE SECTION INNER WING ASSEMBLY (39) - FRAMES AND BALLASTING

1

88775

LUBE NIPPLE,1/4"-28

4шт.

2

9706701

BOLT,Hex, 3/4" - 10 x 2 1/2", Gr 5

4шт.

3

280286

NUT,1"-8, GB

3шт.

4

280210

BOLT,Hex, 3/4"-10 x 4", G5

2шт.

5

88902

NUT,3/8"-16

2шт.

6

87337

BOLT,Hex, 3/4" - 10 x 3", Gr 5

1шт.

7

85700693

NUT,5/8" - 11, Gr C

2шт.

8

280375

NUT,3/4"-10, GC

6шт.

9

86511191

WASHER,0.81" ID x 2" OD x 0.15" Thk

2шт.

10

86523224

BUSHING,25.58mm ID x 32.77mm OD x 26.16mm L

tension 1 1/4" x 1" x 1" long

2шт.

11

3951

U-BOLT

us 5/8"-11 4 1/16" w 5 3/8" d GR5

1шт.

12

88381

BOLT,Hex, 1" - 8 x 5", Gr 5

2шт.

13

5887

RUBBER PAD

wing rest

1шт.

14

87323802

NUT

1 1/4"-12, GB

1шт.

15

22903

DECAL

retroreflective amber 2" x 9"

3шт.

17

87508081

BOLT

EL 3/8"-16 x 1 1/2"

2шт.

18

6252

WASHER

1 1/16" id x 3" od x 1/4" thick

2шт.

19

87019495

SNAP RING,#98, Ext

2шт.

20

87323803

LOCK NUT

1 1/2"-12, GC

2шт.

21

87437292

HYDRAULIC CYLINDER,Double Acting, 44.45mm Rod, 812.8mm Stroke

4" x 32" mon 3000 psi without pins

1шт.

Refer to 35.900.05

1шт.

87437292R

REMAN-HYD CYLINDER

600 (7/08-)

1шт.

87437292C

CORE-HYD CYLINDER

Return Number

1шт.

22

6566

DECAL

grease 50 hours

4шт.

23

8972

PIN

cylinder, 1" x 3 3/8" ul with snap ring groove (#437324)mo

1шт.

Monarch Cylinders - clevis end

1шт.

23

3326

PIN

cylinder 1" x 2 7/8" ul hardened with snap rings

1шт.

Monarch Cylinders - rod end

1шт.

24

87420247

BUSHING,31.85mm ID x 38.19mm OD x 25.4mm L

gar mgl 1 1/2" x 1 1/4" x 1" polygon

2шт.

25

7809

BUSHING

spherical 2 7/16" od x 1 1/2" id sealed

1шт.

26

7825

GROOVED BUSHING

tension 1 3/4" x 1 1/2" x 1 1/2" long

1шт.

27

7860

WASHER

1 1/16" id 3 3/16"

2шт.

28

280260

BOLT,Hex, 3/8" - 16 x 3", Gr 8

1шт.

29

432583A1

WASHER

1.52" id x 4.25" od x .188" thick

1шт.

30

432584A1

WASHER

1.52" id x 3.5" od x .188" thick

1шт.

31

CA-136

TUBE

poly 2 3/4" od x 1 1/4" id x 2 1/2" long

2шт.

32

ND-543

ROLLER

ramp hinge 4" x 1 1/4" x 3/4"

2шт.

33

NW-371

LEVER

lift 95º for 9' wing

1шт.

Includes two of 6636

1шт.

34

NW-380

LINK

rest, inner

2шт.

35

NW-383

LINK

rest for 9' wing, 95º

1шт.

36

NW-389

PEDESTAL

wing rest 155º

1шт.

37

432560A1

FRAME

9' 95º rear wing LH

1шт.

Includes 7809, NW-505, 64601C1, 7825, three of 6566, two 22903, and two TC-500.08

1шт.

37

432561A1

FRAME

9' 95º rear wing RH

1шт.

Includes 7809, NW-505, 64601C1, 7825, three of 6566, two 22903, and two TC-500.08

1шт.

Not Shown

1шт.

38

NW-450V2

BOLT

1 1/2"-12 x 5 3/8" hardened

2шт.

39

NW-475

PIN

1 1/4" x 5"

1шт.

40

NW-478

BOLT

1 1/4"-7 x 6"

1шт.

41

NW-505

BUSHING,58.75mm ID x 73.71mm OD x 31.75mm L

mounting shell, spherical - 1 1/2" ball

1шт.

42

NW-579

BOLT

1"-8 x 9 1/8"

1шт.

43

NW-631

BRACKET

hinge, female 3 1/4"

1шт.

44

432465A1

FRAME

9' front wing LH

1шт.

Includes 64601C1 and 6566

1шт.

44

432464A1

FRAME

9' front wing RH

1шт.

Includes 64601C1 and 6566

1шт.

45

TC-500.08

DECAL

raised wings

1шт.

46

88902

NUT,3/8"-16

1шт.
