Артикул
Название
Примечание
Количество
1
218-5058
HYD CONNECTOR,9/16" - 18 Male JIC x 3/4" - 18 Male ORB
ADAPTER - straight, 9/16-18 flare x 3/4-16 inch O-ring boss
2шт.
2
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
8-1, 90 Duro, .644" ID x .087" Thk
1шт.
3
1284264C1
HYDRAULIC HOSE
HOSE - 7365 mm (290 inch) long
2шт.
4
218-593
TEE,9/16"-18, 37 Degree
- 9/16-18 inch flare branch x flare x flare
2шт.
5
95778C1
HYDRAULIC HOSE,9.65 mm ID x 1778.00 mm, SAE 100 R1
2шт.
6
218-5128
ELBOW,90° Elbow, 9/16" - 18 Male JIC x 3/4" - 16 Male ORB
- 90 degree, 9/16-18 flare x 3/4-16 inch adj O-ring boss
12шт.
7
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
8-1, 90 Duro, .644" ID x .087" Thk
1шт.
8
129782C2
HYDRAULIC HOSE
HOSE - 4191 mm (165 inch) long
2шт.
9
1284367C1
HYDRAULIC HOSE,9.53mm ID x 2415mm L
HOSE - 2415 mm (95 inch) long
2шт.
10
1272485C92
CYLINDER ASSY.
CYLINDER ASSEMBLY - 102 (4) ID x 203 mm (8 inch) stroke (See Page 8-47)
2шт.
10
87423777R
REMAN-HYD CYLINDER
Reman for New PN 1272485C92
2шт.
10
87423777C
CORE-HYD CYLINDER
Return Number
2шт.
11
1282328C92
CYLINDER ASSY.
CYLINDER ASSEMBLY - 95 (3-3/4) ID x 203 mm (8 inch) stroke (See Page 8-45)
2шт.
11
87423766R
REMAN-HYD CYLINDER
CYLINDER ASSEMBLY - 95 (3-3/4) ID x 203 mm (8 inch) stroke (See Page 8-45)
2шт.
11
87423766C
CORE-HYD CYLINDER
Return Number
2шт.
12
1282324C93
CYLINDER
ASSEMBLY - 89 (3-1/2) ID x 203 mm (8 inch) stroke (See Page 8-43)
2шт.
12
84255910R
REMAN-HYD CYLINDER
4300, Reman For New P/N 1282324C93
2шт.
12
84255910C
CORE-HYD CYLINDER
Return Number
2шт.
13
1284290C1
HYDRAULIC HOSE
HOSE - 8130 mm (320 inch) long
2шт.
14
515-23111
CLAMP,7/16", Insul, 3/8" Bolt
- P-type, 7/16 inch ID
1шт.
14
515-23159
CLAMP,5/8", Insul, 3/8" Bolt
P-type 5/8", Insul, 3/8" Bolt
1шт.
15
434-616
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
BOLT - carriage, 3/8 NC x 1 inch
1шт.
16
80680
LOCK WASHER,3/8 0.381 CST ZND
WASHER, LOCK, 3/8"
1шт.
17
425-106
NUT,3/8"-16, Cl 5
1шт.
18
386170C1
CABLE TIE,.30" x 27 1/2"
STRAP - tie
1шт.
Выбрано товаров: 25
