(AT-21) - THREE-POINT QUICK-ATTACHABLE HITCH CATEGORY III, FOR UNITS B, E, F, J AND K

Запчасти Case IH 353 (AT-21) - THREE-POINT QUICK-ATTACHABLE HITCH CATEGORY III, FOR UNITS B, E, F, J AND K

Схема запчастей Case IH 353 - (AT-21) - THREE-POINT QUICK-ATTACHABLE HITCH CATEGORY III, FOR UNITS B, E, F, J AND K
2
4
3
1
4
3
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

490156R1

SPINDLE

ASSY

1шт.

2

401233R1

COLLAR

thrust

2шт.

19998R1

PIN,1/2" x 2 1/2", Coiled

2шт.

3

113225C1

PIN

ASSY, hitch

2шт.

4

373025R91

PIN ASSY.

PIN ASSY, quick attachable snap

2шт.
