Запчасти Case IH 144 (L-04) - UNIVERSAL MOUNTING FRAME, LEFT FRAME

1

PO27491A

ROD

BEAM, gang left, 1-3/8 in. dia

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

2шт.

608085R1

WASHER

1.406 x 2.000 x .054

1шт.

2

PO3103B

BEAM

CLAMP, gang beam and tool bar left

1шт.

18798R1

BOLT,Hex, 7/16"-14 x 2", G2

7/16 x 2 type 1

2шт.

3

516766R1

YOKE

CLEVIS, upper parallel link adjusting

1шт.

432-1216

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

1шт.

512654R1

PIN

5/8 x 2-3/4 in. pointed headed

1шт.

4

516769R21

LINK ASSY.

LINK ASSEMBLY, upper parallel left

1шт.

516773R1

NUT

1/8 in. jam

1шт.

432-1628

COTTER PIN,1/4" x 1 3/4"

Pin, Split (Cotter), 1/4" x 1 3/4"

1шт.

608700R1

WASHER

1.281 x 2.000 x .054

1шт.

5

PO28913

BAR

frame left, 1-1/2 in. sq

1шт.

511961R2

BOLT,Hex, 5/8" - 11 x 1 1/2"

SCREW, 5/8 x 1-1/2 in. special point cap

2шт.

6

PO3101B

ARM

BEARING, gang beam left

1шт.

18941R1

BOLT,1/2" - 13 x 2 3/4", Gr 2

1/2 x 2-3/4 sq-hd mach type 1

2шт.

18942R1

BOLT,1/2" - 13 x 3", Gr 2

1/2 x 3 sq-hd mach type 1

2шт.

120384

WASHER,1/2"

LOCK, 1/2"

2шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

2шт.
