(A-26[B]) - THREE-POINT QUICK-ATTACHABLE HITCH CATEGORY III UNITS D THROUGH L, N AND R THROUGH AD, AH, AP, AQ, AS, AT, AU AND AV

Запчасти Case IH 133 (A-26[B]) - THREE-POINT QUICK-ATTACHABLE HITCH CATEGORY III UNITS D THROUGH L, N AND R THROUGH AD, AH, AP, AQ, AS, AT, AU AND AV (09) - CHASSIS

Схема запчастей Case IH 133 - (A-26[B]) - THREE-POINT QUICK-ATTACHABLE HITCH CATEGORY III UNITS D THROUGH L, N AND R THROUGH AD, AH, AP, AQ, AS, AT, AU AND AV (09) - CHASSIS
4
3
2
2
4
1
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

490156R1

SPINDLE

ASSY, category III w/cat. II spacing

1шт.

1

57233C1

SPINDLE

ASSY, category III

1шт.

1

137083C1

SPINDLE

ASSY, category III, units AE, AF & AG

1шт.

2

401233R1

COLLAR

COLLAT, thrust

2шт.

19998R1

PIN,1/2" x 2 1/2", Coiled

2шт.

3

113225C1

PIN

ASSY, ball

2шт.

4

373025R91

PIN ASSY.

PIN ASSY, quick attachable

2шт.

Выбрано товаров: 7
