Запчасти Case IH 1300W (66) - REFLECTORS AND SMV SYMBOL

1

A59450

WARNING SIGN

SYMBOL - SMV

1шт.

2

A8179

SOCKET

BRACKET - SMV

1шт.

3

T52970

BRACKET - mounting

1шт.

4

111-202

CARRIAGE BOLT,Short NK, 5/16"-18 x 3/4", G2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2

2шт.

5

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

2шт.

6

9635082

NUT,5/16" - 18, Gr 5

2шт.

7

321-5813

REFLECTOR - red

2шт.

8

321-5814

DECAL

REFLECTOR - amber

1шт.

11

321-2574

DECAL - Case

2шт.

12

321-5596

DECAL - Model 1300

1шт.

13

321-4390

DECAL - Warning - Raising Wing

2шт.

14

321-3890

DECAL

- Warning - Lower or Block

1шт.

15

321-3851

DECAL - Warning - Raised Wing

1шт.

16

321-3924

DECAL - Warning - Lock Pins

2шт.

17

321-5687

DECAL - Warning - Wing Drop

1шт.

321-5629

DECAL - Warning (French) Not illustrated

1шт.
