Запчасти Case IH 1200M-SERIES (100) - HARROW, 3 BAR, SHORT, LONG

1

T54967

BRACKET

MOUNTING BRACKET

2шт.

2

T54973

CARRIER ARM

2шт.

3

T54968

PRESSURE ROD

2шт.

4

T54978

CARRIER BRACKET

2шт.

5

T54980

ADJUSTING BRACKET (R)

2шт.

6

T54981

ADJUSTING BRACKET (L)

1шт.

7

T54970

ADJUSTING BRACKET

4шт.

8

T54969

BRACKET

4шт.

9

T51884

SLEEVE

8-3/4" LG.

2шт.

10

T54982

ADJUSTING PLATE

1шт.

11

T54990

MEMBER

FRAME MEMBER (Short)

2шт.

12

T54991

MEMBER

FRAME MEMBER - center (Short)

1шт.

13

T54983

MEMBER

FRAME MEMBER (Long)

2шт.

14

T54984

MEMBER

FRAME MEMBER - center (Long)

1шт.

15

T1937

PIVOT

SWIVEL

2шт.

16

T28942

SPRING

PRESSURE SPRING

2шт.

17

T54975

BUSHING 11/32" LG. (Short)

18шт.

17

T54975

BUSHING 11/32" LG. (Long)

24шт.

18

T54971

SPACER 1-9/16" LG.

2шт.

19

T54974

ADJUSTING BRACKET

2шт.

20

T54976

TOOTH

HARROW TOOTH (Short)

18шт.

20

T54976

TOOTH

HARROW TOOTH (Long)

24шт.

21

111-202

CARRIAGE BOLT,Short NK, 5/16"-18 x 3/4", G2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2

4шт.

22

113-177

BOLT,Hex, 5/16" - 18 x 3", Gr 5

2шт.

23

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3шт.

24

113-425

BOLT,Hex, 1/2" - 13 x 3", Gr 5

23шт.

24

113-425

BOLT,Hex, 1/2" - 13 x 3", Gr 5

29шт.

25

113-424

BOLT,Hex, 1/2" - 13 x 1", Gr 5, Full Thd

4шт.

26

T54979

U-BOLT

3/8"

6шт.

27

T50871

U-BOLT

1/2" H.T.

2шт.

28

T28980

CLEVIS PIN

1/2" x 1-1/2"

2шт.

29

131-176

LOCK NUT,Prev Torque, Hex, 5/16" - 18, Gr A

NUT, hx. lock 5/16"

6шт.

30

230-4216

LOCK NUT,3/8"-16, GA

NUT, hx. lock center 3/8"

15шт.

31

131-1116

LOCK NUT,1/2"-13, GB

NUT, hx. top lock 1/2" (Short)

37шт.

31

131-1116

LOCK NUT,1/2"-13, GB

NUT, hx. top lock 1/2" (Long)

43шт.

32

113-447

BOLT,Hex, 1/2" - 13 x 3-1/2", Gr 5

4шт.

33

195-106

WASHER,1/2"

flat (Short) 1/2"

22шт.

33

195-106

WASHER,1/2"

flat (Long) 1/2"

28шт.

34

T28981

HAIRPIN COTTER 2-3/4" LG.

2шт.

35

T54972

WASHER (Tire fabric)

2шт.

35a

T55041

SPACER 1-15/16" LG.

2шт.

36

T54992

END BRACE (R)

1шт.

37

T54993

END BRACE (L)

1шт.

38

T54977

EXTENSION, end brace

3шт.

39

T54976

TOOTH

HARROW TOOTH, end brace

3шт.

40

T54975

BUSHING 11/32" LG., end brace

3шт.

41

113-425

BOLT,Hex, 1/2" - 13 x 3", Gr 5

End brace Hex, 1/2"-13 x 3", G5

3шт.

42

131-1182

LOCK NUT,1/2"-13, GA

NUT, hx. lock center 1/2", end brace

3шт.

43

195-106

WASHER,1/2"

flat , end brace 1/2"

3шт.
