Запчасти Case IH WWC37-SERIES (12) - HYDRAULIC WING LIFT

1

T52286

STRAP

- lockup (1972)

2шт.

2

T52292

CYLINDER

- wing lift w/pins (See page 14) (1972)

2шт.

3

T52287

ARM - pivot (1972)

2шт.

4

T52288

ARM (1972)

4шт.

5

113-716

BOLT,Hex, 3/4" - 10 x 3", Gr 5

(1972) Hex, 3/4"-10 x 3", G5

2шт.

195-46

WASHER,3/4" x 1 3/4" x .148"

- 1-3/4" x 13/16" x 10 ga.

4шт.

232-46112

LOCK NUT,3/4"-16, GC

LOCKNUT - 3/4" N.C. hex.

2шт.

6

13-1648

BOLT,Hex, 1" - 8 x 3", Gr 5

- 1" x 3" N.C. hex. (1972)

2шт.

131-163

LOCK NUT,1"-8, GA

LOCKNUT - 1" N.C. hex.

2шт.

7

T52671

BRACKET

- pivot arm (1972)

4шт.

8

T52289

PIN - hinge, 1" x 3-1/4" (1972)

4шт.

136-163

HAIR PIN COTTER,Int, 5/16" x .177

COTTER - hairpin

4шт.

9

T52291

U-BOLT

"U" BOLT (1972)

4шт.

192-25

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

8шт.

129-107

NUT,5/8"-11, G5

8шт.

10

T52285

BRACKET - lift arm (1972)

2шт.

11

T52290

PIN

- hinge, 3/4" x 2-1/2" (1972)

2шт.

136-163

HAIR PIN COTTER,Int, 5/16" x .177

COTTER - hairpin

2шт.

12

T53247

STRAP

- lockup (73-)

2шт.

13

T53248

PIN

- hinge, 3/4" x 2-1/2" (73-)

4шт.

136-163

HAIR PIN COTTER,Int, 5/16" x .177

COTTER - hairpin #8

4шт.

14

T53250

CYLINDER

- wing lift w/pins (See page 15A) (73-)

2шт.

15

T53246

ARM - cylinder mount (73-)

2шт.

16

T53249

PIN - hinge, 1" x 2-1/2" (73-)

2шт.

132-150

COTTER PIN,1/4" x 1 1/2"

Pin, Split (Cotter), 1/4" x 1 1/2"

2шт.
