Запчасти Case IH 6750 (001) - MAIN FRAME (WITH COULTER ATTACHMENT) (09) - CHASSIS

1

09576510W

FRAME

pull (7 & 9 shank) - red

1шт.

09576560W

FRAME

pull (11 & 13 shank) -red

1шт.

2

09576200W

FRAME

main (6750 7 & 9 shank) - red

1шт.

09576210W

FRAME

main (6700 7 & 9 shank) - red

1шт.

09576250W

FRAME

main (6750 11 & 13 shank) - red

1шт.

09576260W

FRAME

main (6700 11 & 13 shank) - red

1шт.

3

09573100W

FRAME

coulter (7 & 9 shank) - red

1шт.

09573200W

FRAME

gang coulter (7 & 9 shank) - red

1шт.

09573300W

FRAME

coulter (11 & 13 shank) - red

1шт.

09573400W

FRAME

gang coulter (11 & 13 shank) - red

1шт.

4

09576910

MOUNTING PARTS

cylinder R.H.

1шт.

09576930

MOUNTING PARTS

cylinder L.H.

1шт.

5

09576175

PIVOT

wheel

2шт.

6

09650350

AXLE

ARM spindle R.H. with hub, 783 HUB ASSY.

1шт.

09650360

AXLE

ARM spindle L.H. with hub, 783 HUB ASSY.

1шт.

7

09964000

LOWER LINK

4шт.

8

09650260

SUPPORT ASSY.

hose

1шт.

9

20092051

CLEVIS

double

1шт.

10

20092071

ADJUSTABLE CLEVIS

single

1шт.

11

32230000

JACK

5000 lb

1шт.

12

87393082

CHAIN

safety, 20,200 Ibf

1шт.

14

NSS

NOT SOLD SEPARAT

783 6-BOLT HUB ASSEMBLY

2шт.

16

NSS

NOT SOLD SEPARAT

TIRE 10-ply, 12.5L x 15 (11012150)

2шт.

NSS

NOT SOLD SEPARAT

TIRE 12-ply, 12.5L x 15 (11012152) (11 & 13 shank units)

2шт.

17

10110254

WHEEL ASSY.

with guard - silver, 6-hole, 10 x 15

2шт.

18

09576700

TUBE,79.38" Length

TUBE torque, (79-3/8") (7 shank)

1шт.

09576720

TUBE,101.88" Length

TUBE torque, (101-7/8") (9 & 13 shank)

1шт.

09576740

TUBE,132.38" Length

TUBE torque, (132-3/8") (11 shank)

1шт.

19

09576760

LINKAGE

cylinder

1шт.

20

09576880

FRAME, HITCH

WING stub (13 shank only)

2шт.

21

09576610

LINKAGE

flat

4шт.

22

09100131

WEAR PLATE

2шт.

23

192849A2

DECAL

case IH - 6700 & 6750 units

1шт.

Used On 2006 And Prior Units

1шт.

23

87595770

DECAL

Case IH

1шт.

Used On 2007 And After Units

1шт.

23

87594280

DECAL

Case IH

1шт.

Used On 2008 And After Units

1шт.

23

87653276

DECAL

Case IH

1шт.

24

18535018

DECAL

case IH - 6700, L.H.

1шт.

18535017

DECAL

case IH - 6700, R.H.

1шт.

25

18534192

DECAL

turning

1шт.

26

18534189

DECAL

depth indicator

1шт.

27

18534347

WARNING DECAL

warning sign, towing hazard

1шт.

28

18534228

DECAL

caution sign

1шт.

29

18534107

DECAL

patent

1шт.

30

14810251

HEADED PIN,15.88mm OD x 96.77mm L

clevis, 5/8" Diameter x 3-1/8"

1шт.

31

14816180

HEADED PIN

clevis, 1" Diameter x 3"

4шт.

32

09576180

HITCH PIN

2шт.

33

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

34

16010085

BOLT

hex, 5/8" x 2" NC, GD. 5

2шт.

35

413-12136

BOLT,Hex, 3/4" - 10 x 8-1/2", Gr 5

6шт.

36

413-1444

BOLT,Hex, 7/8" - 9 x 2-3/4", Gr 5

8шт.

37

14820445

CLEVIS PIN,31.75mm OD x 160.27mm L

1-1/4" Diameter x 5-1/2"

1шт.

38

425-106

NUT,3/8"-16, Cl 5

2шт.

39

425-1010

NUT,5/8"-11, G5

2шт.

40

425-1012

NUT,3/4"-10, G5

6шт.

41

425-1114

NUT,7/8"-14, G5

22шт.

42

425-1414

JAM NUT,Jam, 7/8"-9, G5

8шт.

43

87613280

WASHER,1.28" ID x 2.5" OD x 0.25" Thk

1шт.

44

17627010

WASHER,41.67mm ID x 60.33mm OD x 2.08mm Thk

WASHER GA., 1-5/8" x 14

4шт.

45

NSS

NOT SOLD SEPARAT

PIN hair, 1/8" x 2" (14720411)

1шт.

46

14710814

SMALL PIN

klik, 1/4" Diameter x 1-3/4"

1шт.

47

432-1624

COTTER PIN,1/4" x 1 1/2"

6шт.

48

219-86

LUBE NIPPLE,1/8" NPTF

Straight

4шт.

49

14816382

SMALL PIN

clevis, 1" x 3-3/4"

2шт.

50

413-14136

BOLT,Hex, 7/8" - 9 x 8-1/2", Gr 5

6шт.

52

09650333

SHIM,.134" Thk

1шт.

53

17620020

BUSHING,32.15mm ID x 47.63mm OD x 2.08mm L

machined, 1-1/4"

1шт.

54

14892066

PIN

1-1/4" x 8-1/2"

1шт.

55

413-740

BOLT,Hex, 7/16" - 14 x 2-1/2", Gr 5

2.P.

1шт.

56

230-4117

LOCK NUT,7/16"-14, GA

1шт.

57

413-1640

BOLT,Hex, 1" - 8 x 2-1/2", Gr 5

1шт.

58

425-1016

NUT,1"-8, G5

1шт.

59

413-1448

BOLT,Hex, 7/8" - 9 x 3", Gr 5

4шт.

60

413-12104

BOLT,Hex, 3/4" - 10 x 6-1/2", Gr 5

24шт.

61

413-1248

BOLT,Hex, 3/4" - 10 x 3", Gr 5

20шт.

62

425-1012

NUT,3/4"-10, G5

28шт.

63

18534367

ADHESIVE

STRIP amber reflective

6шт.

64

18534363

ADHESIVE STRIP

red reflective

2шт.

65

09576890

SHANK

inner mount (9, 11, & 13 shank only)

2шт.

67

09576875

ANGLE

6шт.

69

120213C1

DECAL

EMBLEM SMV

1шт.

70

06000099

BRACE

BRACKET SMV

1шт.

71

16309101

U-BOLT,3/8" - 16, Square, 4" W x 6" L

BOLT "U" 3/8" x 4" x 6"

1шт.

72

231-4116

NUT,3/8"-16, GB

14010601

2шт.

73

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

2шт.

74

230-4114

NUT,1/4"-20, GA

2шт.

75

04681210

BRACKET

1шт.

76

04681211

BUSHING

SPACER

1шт.

77

230-41116

NUT,1"-8, GA

1шт.

78

413-1648

BOLT,Hex, 1" - 8 x 3", Gr 5

1шт.

79

496-41081

WASHER,13/16" x 1 3/4" x .219", HDN

12шт.

80

18534277

DECAL

warning sign - spring compression

1шт.

82

18534364

INDICATOR STRIP

fluorescent

2шт.
