Запчасти Case IH 645 (A-3[01]) - KIT VIBRA CHISEL SHANK ASSY

1

813176C92

SHANK

Incl 2 - 16

1шт.

2

21375R1

WASHER

1шт.

3

492-11062

BEARING WASHER,5/8"

1шт.

4

138506

LOCK WASHER,Ext Tooth, 3/4"

2шт.

5

9413967

LOCK NUT,1/2"-13, GB

1шт.

6

280374

NUT,Hex, 5/8" - 11, Gr 5

1шт.

7

425-1012

NUT,3/4"-10, G5

1шт.

8

271548

BOLT (SPREADER),Hex, 5/8" - 11 x 1 3/4", Gr 5

1шт.

9

271781

BOLT (SPREADER),Hex, 3/4" - 10 x 4 1/2", Gr 5

1шт.

10

811340C3

BOLT,1/2" - 13 x 5 1/2"

1шт.

11

812760C1

BUSHING,19.3mm ID x 26.92mm OD x 76.2mm L

1шт.

12

1284063C1

LARGE PLATE

2шт.

13

813161C1

CLAMP

1шт.

14

813162C2

SUPPORT

1шт.

15

811334C1

CLAMP

1шт.

16

813160C2

SHANK

1шт.
