Запчасти Case IH 55 (C-21) - 55 CONSER-TILL GANG SUPPORT, 10 FOOT AND 13 FOOT MODELS

1

812402C91

ARM

ASSY, disk gang LH, 10 and 13 foot models

4шт.

1

812403C91

ARM

ASSY, disk gang RH, for use on 13 foot model only, includes 1-596781R1, bushing

2шт.

180175

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

1/2-13 x 1-1/4 hex-hd, 3 bolts used per arm assy

1шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, , 1 nut per bolt 1/2"-13, G5

1шт.

120384

WASHER,1/2"

LOCK, , 1 per bolt 1/2"

1шт.

2

596781R1

BUSHING,15.95mm ID x 52.32mm OD x 65.02mm L

gang pivot, 1 used per arm assy

1шт.

3

596784R1

WASHER

pivot bushing, 1 used per arm assy

1шт.

4

812396C1

SUPPORT

gang pivot LH

1шт.

5

812397C1

SUPPORT

gang pivot RH, 1 used per arm assy

1шт.

413-1072

BOLT,Hex, 5/8" - 11 x 4-1/2", Gr 5

5/8-11 x 4-1/4 hex-hd, 1 per support

1шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 hex, 1 per bolt

1шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, , 1 per bolt 5/8"

1шт.

6

609133R1

VALVE SPRING

SPRING, gang lift, 1 used per arm assy

1шт.

7

608348R1

RETAINER

PLUG, spring, 2 used per arm assy

1шт.

8

812409C1

ROD

ASSY, lift spring, 1 used per arm assy

1шт.

446257

WASHER,3/4" x 1 3/4" x .148"

.812 x 1.750 x .122, 13 foot model only

4шт.

280954

NUT,3/4"-10, G5

1 used per rod 3/4"-10, G5

1шт.

426897

JAM NUT,Jam, 3/4"-10, G5

3/4-10 hex. jam, 1 per rod

1шт.

467750R1

WASHER

.781 x 1.500 x .105, 1 washer used per rod

1шт.

21932R1

HEADED PIN,1/2" x 2"

PIN, 1/2 x 2 std-hd-dld, 1 per rod

1шт.

432-1216

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), , 1 per pin 3/16" x 1"

1шт.

9

812443C1

WASHER

spring rod, 1 per rod assy

1шт.

10

812444C1

PIVOT

gang spring, 1 per rod assy

1шт.

11

812394C2

ANGLE

gang support LH

1шт.

12

812395C2

ANGLE

gang support RH, 1 per spring pivot

1шт.

180194

BOLT,Hex, 1/2" - 13 x 4", Gr 5

1/2-13 x 4 hex-hd, 1 bolt used per support

1шт.

445608

BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5

1/2-13 x 5-1/2 hex-hd, 4 bolts used per angle

1шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, , 1 nut per bolt 1/2"-13, G5

1шт.

9413967

LOCK NUT,1/2"-13, GB

NUT, 1/2 CAD P/T lock type 5, 1 per bolt

1шт.
