Артикул
Название
Примечание
Количество
1
395149R1
QUICK MALE COUPLING
COUPLER, hydraulic hose male or
2шт.
1
544787R91
COUPLING, BREAK AWAY
COUPLER, hydraulic, recommended hydraulic parts
2шт.
2
364885R1
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
hydraulic coupler, recommended hydraulic parts
2шт.
3
811270C1
HOSE
80 in. hydraulic front not for use w/check valve
2шт.
4
TUBE ASSY, 174.8 inch in. length, for service order 1-813066C1 tube & 1-813087C1 tube
2шт.
5
813086C1
TUBE,0.375" OD, 87.4" Length
ASSY, hyd front extension
2шт.
6
813087C1
TUBE,0.375" OD, 87.4" Length
ASSY, hydraulic front
2шт.
7
614323R2
CLAMP
hydraulic tube
13шт.
9635884
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
5/16 x 1 type 5
9шт.
413-528
BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5
5/16 x 1-3/4 type 5
4шт.
120376
NUT,5/16"-18, G5
13шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
13шт.
8
812670C1
TUBE
ASSY, hydraulic corner
2шт.
9
812668C1
TUBE,0.375" OD, 50.5" Length
ASSY, hydraulic RH cylinders
2шт.
10
813077C1
HOSE ASSY.
HOSE, 55 in. rockshaft master hydraulic cylinder
4шт.
11
9410977
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring
3/4-16 hyd 37 deg flared tube 90 deg w/nut and washer
8шт.
13
813006C1
HOSE
85 in. hyd cyl jumper
2шт.
14
813003C1
TUBE,0.375" OD, 64" Length
ASSY, slave cyl hydraulic
4шт.
15
879612C1
HOSE
32.5 in. slave cylinder hyd
4шт.
16
306132C1
CABLE TIE,14.5" L
TIE, hydraulic hoses, 816502C1
4шт.
17
24581R1
PIN
1 x 3-1/2 std-hd-dld znd type 5
8шт.
432-1620
COTTER PIN,1/4" x 1 1/4"
Pin, Split (Cotter), 1/4" x 1 1/4"
8шт.
18
812368C91
CYLINDER
ASSY, hyd 3.5 x 8 DA master, Cessna, for components refer to hydraulic cylinders section L
2шт.
19
812367C91
CYLINDER
ASSY, hyd 3.25 x 8 da slave, Cessna, for components refer to hydraulic cylinders section L
2шт.
87423770R
REMAN-HYD CYLINDER
5000 INTERNATIONAL HARVESTER VIBRA CHISEL, Reman for New P/N 812367C91
2шт.
87423770C
CORE-HYD CYLINDER
Return Number
1шт.
19
149920C91
CYLINDER
ASSY, hyd 3.5 x 8 DA master, IH, replaces 149996C91 & 812735C92, for components refer to hydraulic cylinders section L
2шт.
24581R1
PIN
1 x 3.500 hd type 5
4шт.
432-1620
COTTER PIN,1/4" x 1 1/4"
Pin, Split (Cotter), 1/4" x 1 1/4"
4шт.
20
149919C92
CYLINDER
ASSY, hyd 3.25 x 8 DA slave, IH, replaces 812736C91
2шт.
87423770R
REMAN-HYD CYLINDER
5000 INTERNATIONAL HARVESTER VIBRA CHISEL, Reman for New P/N 149919C92
2шт.
87423770C
CORE-HYD CYLINDER
Return Number
1шт.
20
810311C91
CYLINDER
ASSY, hyd 3.25 x 8 DA slave, Prince, for components refer to hydraulic cylinders section L
2шт.
87423770R
REMAN-HYD CYLINDER
5000 INTERNATIONAL HARVESTER VIBRA CHISEL, Reman for New P/N 810311C91
2шт.
87423770C
CORE-HYD CYLINDER
Return Number
1шт.
24581R1
PIN
1 x 3.500 hd type 5
4шт.
432-1620
COTTER PIN,1/4" x 1 1/4"
Pin, Split (Cotter), 1/4" x 1 1/4"
4шт.
21
651793R2
SUPPORT
flexible hose
1шт.
413-1032
BOLT,Hex, 5/8" - 11 x 2", Gr 5
5/8 x 2 type 5
1шт.
280374
NUT,Hex, 5/8" - 11, Gr 5
5/8 type 5
1шт.
492-11062
BEARING WASHER,5/8"
WASHER, LOCK, 5/8"
1шт.
464623R1
WASHER
.656 x 1.500 x .105
2шт.
22
813002C1
TUBE
hyd extension w/E frame
4шт.
23
9410332
TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run
9/16-18 hyd 37 deg flared tube 90 deg swivel
2шт.
Выбрано товаров: 45
