Запчасти Case IH PATRIOT NT (03-006) - STRUT ASSEMBLY - REAR Suspension & Frame

1

BN80442

DUST CAP

2шт.

2

BN80443

LOCK NUT

4шт.

3

BN80444

LOCK WASHER,2.026" ID x 2.95" OD x 0.015"

lock, bearing

4шт.

4

BN31073

ROLLER BEARING,2" ID x 3.6718" OD x 1.1875"

4шт.

5

ST863

BEARING CUP,93.22mm OD x 23.81mm W

#3720

4шт.

6

BN29071

HUB

Assembly With Race and Seal

4шт.

Includes Ref. 5

1шт.

BN29058

SHIM

8" Dia x 12 ga

1шт.

7

BN31074

SEAL

4шт.

8

BN66894

PLATE

(Model #7 Hub)

2шт.

BN50320

Bolt- 5/8" x 2 1/4" G8

8шт.

BN50775

LOCK NUT

5/8"-18 UNF Center

8шт.

87343677

NUT

Hex, 5/8"-18, G8

8шт.

9

BN29081

4шт.

10

BN66421

HOUSING

LH

1шт.

BN66420

HOUSING

RH

1шт.

11

BN27333

SERVICE KIT

Shock, Bushing, Bolt, Nut

2шт.

12

BN25273

SUPPORT

L.H.

1шт.

BN25274

SUPPORT

R.H.

1шт.

13

BN29690

DEFLECTOR

2шт.

14

BN24159

COIL SPRING

Extra H.D.

2шт.

BN24261

RETAINER,13.46mm ID x 101.6mm OD x 6.35mm Thk

4" od x .53" id x 1/4"

4шт.

15

BN25583

L.H.

1шт.

BN25576

R.H.

1шт.

16

BN25740

L.H.

2шт.

17

BN25473

LINER

LH

4шт.

BN25472

LINER

RH

2шт.

18

BN25472

LINER

RH

2шт.

BN25617

LINER

RH

2шт.

19

BN68788

DUST CAP

w/Drill & Tap

4шт.

20

BN10465

NIPPLE, LUBE,1/4"-28 st

NIPPLE

4шт.
